Nabco 710 User Manual

Model 710 Swing Door System
NABCO
ENTRANCES INC 877-622-2694 www.nabcoentrances.com - 7 -
Hardware Kit List
This kit has been shipped with the following installation hardware.
MAGNUM IV RETRO FIT for SINGLE – P/N 11-10361-01
MAGNUM IV RETRO FIT for SIM.PAIR – P/N 11-10361-02
QtyPart # Part Description
Single Sim-
Pair
Notes
All items (#1~#24) would be packed into 8”x6”x6” box (P/N 14-1159).
1 24-9800-04 Magnum IV Control Board 1 2
2 22-10065 Main Harness - Single 1 --- With Terminal Block
3 22-10270 Main Harness – Simultaneous Pair --- 1 With Terminal Block
4 11-10286 Motor Harness 1 2 Four Pin Connector
5 21-9933 Power Harness - Single 1 ---
6 14-5883 Power Harness – Simultaneous Pair --- 1
7 11-10272 Rocker Switch Assy 1 1 No connector
8 21-9941-01 Magnetic Switch Assy - RH --- 1
9 21-9941-02 Magnetic Switch Assy - LH --- 1
10 21-10005 Magnetic Switch Plate Assy 1 ---
11 14-9940-01 Label for RH Operator 1 ---
12 14-9940-02 Label for LH Operator 1 ---
Use one of Labels.
13 15-10677 GT710 Retrofit Kit Manual 1 1
Packed into a 3”x4” ziplock bag (P/N 14-0828-01).
14 14-9944 Epoxy Package & Stir Stick 1 2
Packed into a 4”x6” ziplock bag (P/N 14-0828-03).
15 14-9960 Wire Saddle 3 6
16 24-1447 Wire Harness Clip 4 8
17 14-9959 Cable Clamp --- 4
18 14-9943 Ceramic Magnet 2 4
19 14-8743 Spacer for Magnum Board 4 8
20 14-1218 Wire Nut 2 4
21 14-1838 Male Pin Housing , 4 circuit 1 --- For Magnetic Switch
22 24-0011-014 #10-32x1/2” Phillips Black Oxide
Screw
2 2 For Rocker Switch
23 24-4941-19 3/8-16x3/4” Hex Washer Head Screw,
F
2 4 For Magnetic Switch
24 24-0010-01 #10-24x7/8” Socket Head Cap Screw 4 8 For Magnum Board

Nabco 710 Specifications

General

Brand	Nabco
Model	710
Category	Door Opening System
Language	English
