Model 710 Swing Door System
NABCO
ENTRANCES INC 877-622-2694 www.nabcoentrances.com - 8 -
LED
TRANSFORMER
CAPACITOR
O F F
1 2
AUX
PWR
4
J2
3
J5
AC IN
F2
SW2
SW1
F1
RELAY
R2
RELAY
R3
J4
R4 R5 R6 R7 R8
TDAS
SIGNAL
INPUT
TDPG LCHK CLOSE
Fuse 2: 0.5A 24 VAC
STOP OPEN BCHK
CURRENT
LIMIT
MOTOR
J1
R28
MAGNUM IV
Fuse 1: 3A 120/240
P/N 24-0010-01
Socket Head Cap Screw
#10-24x7/8"
P/N 24-4941-19
Hex Washer Head Screw, Type F
3/8-16x3/4"
P/N 24-0011-014
Phillips Head Black Oxide Screw
#10-32x1/2"
P/N 14-8743
for Magnum Board
Spacer
P/N 14-1838
4 circuit
Male Pin Housing
P/N 14-1218
Wire Nut
P/N 14-9943
Ceramic Magnet
(2)
Wire Nut
P/N 14-9944
Epoxy & Stir Stick
Epoxy and Stir Stick
P/N 24-1447
Wire Harness Clip
P/N 14-9959
Cable Clamp
P/N 14-9960
Wire Saddle
P/N 14-5883
Power Harness - Sim.Pair
P/N 11-10272
Rocker Switch Assy.
Off
On
Hold Open
Off
P/N 22-10065
Main Harness - Single
P/N 21-9933
Power Harness - Single
1
P/N 11-10286
Motor Harness
P/N 24-9800-04
Magnum IV Board
P/N 22-10270
Main Harness - Sim. Pair
DN0037
Figure 3 – Installation Hardware
