Model 710 Swing Door System
NABCO
ENTRANCES INC 877-622-2694 www.nabcoentrances.com - 5 -
Table 1 – Comparison of Magnum IV to the original GT710 Controller
Magnum IV Board GT710 Controller
Adjustable opening speed. Adjustable opening speed.
Adjustable current limit/door block
trip.
Adjustable current limit/door block
trip.
Adjustable activation timer (0 to 60
seconds)
One adjustable timer for activation and
push-n-go (0 to 60 seconds)
Adjustable separate push-n-go timer
(0 to 60 seconds)
None
Adjustable door action when detection
(continuous safety) occurs – allow
door to stop, creep open or creep
closed.
No adjustment.
Automatic shut-off of motor if door
does not open within 30 seconds.
Shut-off occurs when the timer for
activation expired.
Connection provided for swing side
mats and swing side presence detector
(Continuous safety and safety with
lockout).
N/A
Enable/disable sequential operation
via dip switch.
Enable/disable sequential operation via
onboard jumper.
Enable/disable push-n-go via dip
switch.
Wiring change required to activate
push-n-go.
Specifications
Power Input 120 (±10%) AC 50-60 Hz, 5 Amps
Available current for Accessories 0.5 Amps 24 Volts AC
Available Wire Size for Incoming
Power
14 AWG
Minimum Frame Face for Mounting 1 ¾” (44 mm)
Minimum Clearance from Top of
Door to Ceiling
7” (178 mm)
Door Hinge Requirements ¾” Butt, Offset Pivot, or Center Pivot
Door Thickness 1 ¾” (44 mm) Minimum
Door Width Specify When Ordering
Tools required 5/32” Hex Key (Allen Wrench)
Phillips Screwdriver #2
Slotted Screwdrivers, Small and Medium
Drill Bits: 11/64” and 7/8”
