Nabco GT1175 Quick Setup Guide

43 of 53
www.NabcoEntrances.com GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide
Rev 8-10-16 P/N C-00106

   
1 21-14030 ASM,ENDCAP CARRIER
2 21-14035 ASM,ANTI-RISE,HURR
3 21-14040 ASM,RETAINER, CARRIER ECCENTRIC
4 11-10733 HANGER ROLLER W/URETHANE ASSY, GT1175
5 14-2279-04 PILE WEATHERING, BLK, .20 TALL, CARRIER
6 24-9094-01 Clear INTERFACE LEG - 204
24-9094-02 Dark Bronze INTERFACE LEG - 313
7 24-0014-15 HHCS, 1/4-20 X 3/4, HWH, TRI-LOBE, ZN
8 12-14478 PANIC CATCH UPPER PART,ASSY,
9 24-9483 PANIC CATCH, UPPER PART
10 24-0016-30 SHSS, 5/16-18 X 1.25", CUP
11 24-0010-62 SHCS, #10-32 X 5/8", ZINC
12 21-8419 LIMIT ARM ASSY, MED STILES
13 24-0017-02 WASHER, 7/16 ID X 1 OD X .083 THK
14 12-14195 ASM, INTERLOCK, MALE, HURRICANE
15 14-5592-01 Gray WEATHER STRIP - 9/16 IN VINYL FIN, GRAY
14-5592-02 Black WEATHER STRIP - 9/16 IN VINYL FIN, BLACK
16 24-0019-05 1/4" EXTERNAL STAR WASHER
17 24-0017-04 WASHER, 1/4 ID X 9/16 OD X .049 THK, STL
18 24-0014-12 HHCS,1/4-20 X 1 3/4"
19 24-12002-50 CARRIER PVT ASM - HURR
20 22-3590-04 SCREW - SOCKET FL HD W-VIBR 7/16-14 X 1
21 14-8447 LIMIT ARM SUPPORT
22 21-3468-99 PANIC CATCH RELEASE ASSY, MODEL 1100
23 24-0010-16 SHCS, 1/4-20 X 1 1/4"
24 14-14060 BLOCK GUIDE,LOCKROD
25 14-8326-05 PILE WEATHERING, BLK - LEAD EDGE NO ADH.
26 14-9511-04 PLUG, HOLE, .813 DIAMETER, BLK
27 22-10256 LOCK ROD, SUB ASSY. 7 FT LENGTHS
28 24-0564 HOOKBOLT, DEADLOCK CR LAURENCE
29 24-0565-11 Clear LOCK, COVER W/LATCH CUTOUT 204
24-0565-12 Dark Bronze LOCK, COVER W/LATCH CUTOUT 313
30 24-0011-72 FHMS,10-24 X 3/8", PHIL, UND
31 22-4412 HEADER LOCK ROD ASSY LESS SCREW PACK
32 14-14062 LOCKROD, 1/4"-20
33 24-0020-17 PIN, ROLL 5/32 DIA X 7/8 LONG
34 24-0013-03 Zinc PHSMS, 6 X 1/2", PHIL, TEKS, ZN
24-0013-04 Black Zinc PHSMS, 6 X 1/2", PHIL, TEKS, BLK ZN
35 24-14186-01 Clear BRUSH HOLDER, DOOR, FO, 204 FINISH
24-14186-02 Dark Bronze BRUSH HOLDER, DOOR, FO, 313 FINISH
36 14-4899-100 Brush BRUSH, .007 NYLON BRISTLE, 1.00 OAH
22-4495-01 Silver KEYED ALIKE LOCK CYLINDERS SILVER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
