GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide www.NabcoEntrances.com
P/N C-00106 Rev 8-10-16
37 22-4495-02 Bronze KEYED ALIKE LOCK CYLINDERS BRONZE
38 12-1400-01 Hook Bolt Extends “Up” EXIT INDICATOR,INVERTED,CLEAR FINISH
12-1400-02 Hook Bolt Extends “Up” EXIT INDICATOR,INVERTED,BRONZE FINISH
12-1400-03 Hook Bolt Extends “Down" EXIT INDICATOR,STANDARD,CLEAR FINISH
12-1400-04 Hook Bolt Extends “Down" EXIT INDICATOR,STANDARD,BRONZE FINISH
39 22-0090-01 Silver CYLINDER, THUMB TURN SILVER
22-0090-02 Bronze CYLINDER, THUMB TURN BRONZE
40 24-0012-14 PHMS, #10-32 X .50 LG, PHL, ZINC
41 21-14045 ASM.BTM GUIDE FO
42 24-0021-21 NUT, WHIZLOCK, 3/8-16, ZN
43 14-9225 BACKING PLATE, TIE ROD - DOOR ASSEMBLY
44 14-0984-01 CLIP, 0.386" HOLE
45 14-14192 CLIP,RAIL,2.9L.
46 14-3624 THREADED ROD, 3/8"-16 - ZINC PLATED
47 14-9279 OFFSET TEE NUT, 3/8"-16
48 14-0984-02 CLIP, 1/2" HOLE
49 24-0011-131 FHMS, 10-32X1/2", PHIL, TYP 23, UND, ZN
50 24-0016-42 SCREW,SET 5/16-24 X 5/8, CUT POINT
39
40
41
42
43
44
45
46
47
48
49
38
50
37
