GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide www.NabcoEntrances.com
P/N C-00106 Rev 8-10-16

   
1 21-14030 ASM,ENDCAP CARRIER
2 21-14035 ASM,ANTI-RISE,HURR
3 21-14040 ASM,RETAINER, CARRIER ECCENTRIC
4 11-10733 HANGER ROLLER W/URETHANE ASSY, GT1175
5 14-2279-04 PILE WEATHERING, BLK, .20 TALL, CARRIER
6 24-9094-01 Clear INTERFACE LEG - 204
24-9094-02 Dark Bronze INTERFACE LEG - 313
7 24-0014-15 HHCS, 1/4-20 X 3/4, HWH, TRI-LOBE, ZN
8 12-14478 PANIC CATCH UPPER PART,ASSY,
9 24-9483 PANIC CATCH, UPPER PART
10 24-0016-30 SHSS, 5/16-18 X 1.25", CUP
11 24-4941-26 SCREW, 3/8" X 1", HWH, SMS, TYPE A, ZN
12 21-8419 LIMIT ARM ASSY, MED STILES
13 24-0017-02 WASHER, 7/16 ID X 1 OD X .083 THK
14 14-5592-01 Gray WEATHER STRIP - 9/16 IN VINYL FIN, GRAY
14-5592-02 Black WEATHER STRIP - 9/16 IN VINYL FIN, BLACK
15 24-0019-05 1/4" EXTERNAL STAR WASHER
16 24-0017-04 WASHER, 1/4 ID X 9/16 OD X .049 THK, STL
17 24-0014-12 HHCS,1/4-20 X 1 3/4"
18 24-12002-50 CARRIER PVT ASM - HURR
19 22-3590-0 Error no match found
20 14-8447 LIMIT ARM SUPPORT
21 21-3468-99 PANIC CATCH RELEASE ASSY, MODEL 1100
22 24-0010-16 SHCS, 1/4-20 X 1 1/4"
23 14-14060 BLOCK GUIDE,LOCKROD
24 14-8326-05 PILE WEATHERING, BLK - LEAD EDGE NO ADH.
25 14-9511-04 PLUG, HOLE, .813 DIAMETER, BLK
26 22-10256 Call Customer Service LOCK ROD, SUB ASSY. 7 FT LENGTHS
27 24-0564 HOOKBOLT, DEADLOCK CR LAURENCE
28 24-0565-11 Clear LOCK, COVER W/LATCH CUTOUT 204
24-0565-12 Dark Bronze LOCK, COVER W/LATCH CUTOUT 313
29 24-0011-72 FHMS,10-24 X 3/8", PHIL, UND
30 22-4412 Call Customer Service HEADER LOCK ROD ASSY LESS SCREW PACK
31 14-14062 LOCKROD, 1/4"-20
32 24-0020-17 PIN, ROLL 5/32 DIA X 7/8 LONG
33 24-0013-03 Zinc PHSMS, 6 X 1/2", PHIL, TEKS, ZN
24-0013-04 Black Zinc PHSMS, 6 X 1/2", PHIL, TEKS, BLK ZN
34 24-14186-01 Clear BRUSH HOLDER, DOOR, FO, 204 FINISH
24-14186-02 Dark Bronze BRUSH HOLDER, DOOR, FO, 313 FINISH
35 14-4899-100 Brush BRUSH, .007 NYLON BRISTLE, 1.00 OAH
36 22-4495-01 Silver KEYED ALIKE LOCK CYLINDERS SILVER
22-4495-02 Bronze KEYED ALIKE LOCK CYLINDERS BRONZE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
