53 of 53
www.NabcoEntrances.com GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide
Rev 8-10-16 P/N C-00106
37 12-1400-01 Hook Bolt Extends “Up” EXIT INDICATOR,INVERTED,CLEAR FINISH
12-1400-02 Hook Bolt Extends “Up” EXIT INDICATOR,INVERTED,BRONZE FINISH
12-1400-03 Hook Bolt Extends “Down” EXIT INDICATOR,STANDARD,CLEAR FINISH
12-1400-04 Hook Bolt Extends “Down” EXIT INDICATOR,STANDARD,BRONZE FINISH
38 22-0090-01 Silver CYLINDER, THUMB TURN SILVER
22-0090-02 Bronze CYLINDER, THUMB TURN BRONZE
39 24-0012-14 PHMS, #10-32 X .50 LG, PHL, ZINC
40 21-14050-10 Right Hand ASM, LOWER PIVOT, RH, FS, HURRICANE
21-14050-20 Le Hand ASM, LOWER PIVOT, LH, FS, HURRICANE
41 24-0021-21 NUT, WHIZLOCK, 3/8-16, ZN
42 14-9225 BACKING PLATE, TIE ROD - DOOR ASSEMBLY
43 14-0984-01 CLIP, 0.386" HOLE
44 14-14192 CLIP,RAIL,2.9L.
45 14-3624 THREADED ROD, 3/8"-16 - ZINC PLATED
46 14-9279 OFFSET TEE NUT, 3/8"-16
47 14-0984-02 CLIP, 1/2" HOLE
48 24-0011-131 FHMS, 10-32X1/2", PHIL, TYP 23, UND, ZN
49 24-0016-42 SCREW,SET 5/16-24 X 5/8, CUT POINT
50 14-12948 MAGNET WEDGING STRIP
51 14-8413-02 FLEXIBLE MAGNETIC STRIP
39
40
41
42
43
44
45
46
47
48
49
38
50
37
51
