PREAMPLIFIER SECTION
LINE LEVEL INPUTS DISC, CD, VIDEO, AUX, TUNER, TAPE MONITOR, TAPE2
Input impedance (R and C) 200k KΩ+ 100pF
Input sensitivity (ref. rated power) 300mV
Maximum input signal 6V
Signal / Noise ratio A-weighted
1
98.0dB ref. 1W
Signal / noise ratio pre-amp out, A-weighted 110dB ref. 500mV
Frequency response 20Hz - 20kHz <±0.1dB (Tone defeat on)
<±0.1dB (Tone defeat o)
THD + Noise, SMPTE IM < 0.01% at 5V out
LINE LEVEL OUTPUTS
Output impedance - Pre-out 80 Ω
Tape Source Z + 1kΩ
Maximum output level - Pre-out >11V
Tape >10V
TONE CONTROLS
Treble ±5dB at 10kHz
Bass ±8dB at 100Hz
TRIGGER OUT
Output resistance <120 Ω
Output current 50mA
Output voltage 12V
POWER AMPLIFER SECTION
Continuous output power into 8 Ω
2
80W (19dBW)
Rated distortion (THD 20Hz - 20kHz) 0.02%
Clipping power (maximum continuous power per channel 4 Ω and 8 Ω) 92W
IHF Dynamic headroom - 8 Ω +2.4dB
4 Ω +4.4dB
IHF dynamic power (maximum short term power per channel) - 8 Ω 140W (21.5dBW)
4 Ω 220W (23.4dBW)
2 Ω 270W (24.3dBW)
Damping factor (ref. 8 Ω, 1kHz) >160
Input impedance (R & C) 20kΩ+ 1nF
Input sensitivity (rated output into 8 Ω) 940mV
Voltage gain 29dB
Frequency response 20Hz - 20kHz ±0.1dB
Signal/noise ratio, A-weighted 105dB (ref. 1W )
124dB (ref. rated power)
THD + Noise
3
<0.02%
SMPTE IM
4
<0.01%
IHF IM
5
<0.01%
Headphone output impedance 68 Ω
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) - Net 435 x 116 x 292mm
Gross
6
435 x 130 x 338mm
Net weight 8.5kg
Shipping weight 10.4kg
1 From CD input to speakers output, volume setting for 500mV in, 8 Ω 1W out
2 Minimum power per channel, 20Hz - 20kHz, both channels driven with no more than rated distortion.
3 Total harmonic distortion, 20Hz - 20kHz from 250mW to rated output
4 Intermodulation distortion, 60Hz + 7kHz, 4:1, from 250mW to rated output
5 CCIF IM distortion, 19.5K+1kHz rated output
6 Gross dimensions include feet, volume knob and extended speaker terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 355BEE.
REFERENCE
SPECIFICATIONS
12
