NAD C 541 - Discrete Components and Resistors

24
C537,C538 157E-106M-5-Iuf3 CE 25V 10µF 20% RL 5X11
C539 153F-103K-5-IM CM 50V 0.01µF 10% RL 5x7
C540-C543 150F-104K-5-II CC 50V 0.1µF 10% RL 5x5
C544 153F-103K-5-IM CM 50V 0.01µF 10% RL 5x7
C545,C546 150F-104K-5-II CC 50V 0.1µF 10% RL 5x5
C560,C561 157E-107M-5-KUK CE 25V 100µF 20% RL
C701 153F-103K-5-IM CM 50V 0.01µF 10% RL 5x7
C702 157C-476M-5-IMK CE 10V 47µF 20% RL 5X7
C703 150F-104K-5-II CC 50V 0.1µF 10% RL 5x5
C704 153F-103J-5-IM CM 50V 0.01µF 5% RL 5X7
C710 157B-107M-5-KMK CE 6.3V 100µF 20% RL
C713 153F-223K-5-LQ CM 50V 0.022µF 10% RL 6.
DIODES
D101, D301-D302, D401-D402 4804-1480-2 DIODE 1N4148 AT
D403 4837-3V31-2 DZ 1/2W 3.1-3.5V ROHM AT
D409, D411-D415, D426, D431 4804-1480-2 DIODE 1N4148 AT
D501-D504 4804-0010-2 DIODE 1N4001 AT
D505 4840-1140-0 ZD 1.3W 3.3V 5% AT
D506-D508 4804-0010-2 DIODE 1N4001 AT
D510 4840-0850-0 ZD 1/2W 21.52-22.63V AT
D511 4837-5V61-2 DZ 1/2W 5.6V ROHM AT
D514-D517 4804-0010-2 DIODE 1N4001 AT
COILS
J507, L101 1801-100K-M COIL 10µH 10% BL7.0
L301 1802-0450-0 DIGITAL COIL 015-910-27BB
CRYSTAL
M302 2300-1910-0 X'TAL 16.9344MHZ +/-30PPM AT-51
M303 2704-0060-0 EMC FILTER
M401, M402 2703-6190-0 CR REASONATOR CSA 12MHz
JACKS
M317 2113-1300-0 2P RCA JACK W/R AU W/SHIELD
M318 2113-1170-0 1P RCA JACK YL AU HTJ-032-0
M319 2113-1121-0 2P RCA JACK Y/Y AU HSP-24V-22
TRANSISTORS
Q101 4851-015Y-5 TR 2SA1015-Y HFE120-240
Q301-Q304 4860-1780-5 TR 2SD655F HFE:600-1200
Q305 485A-1346-5 TR 2SA1346 HFE 50-100
Q308 4860-1780-5 TR 2SD655F HFE:600-1200
Q401 4860-0660-5 TR 2SA1015 (G.R.) RL
Q402 4851-012F-5 TR 2SD1012F/G HFE 160-560
Q403 4860-0660-5 TR 2SA1015 (G.R.) RL
Q502 485A-950Y-5 TR 2SA950-Y HFE 100-200
RESISTORS
D701 4701-752J-C RCF 1/8W 7.5K 5% ATS
J519 4715-4R75-2 RMF 1/4W 4.75R 1% AT
R101 4701-154J-C RCF 1/8W 150K 5% ATS
R102 4701-682J-C RCF 1/8W 6.8K 5% ATS
R103 4701-222J-C RCF 1/8W 2.2K 5% ATS
R106 4701-331J-C RCF 1/8W 330R 5% ATS
R107 4701-273J-C RCF 1/8W 27K 5% ATS
R108 4701-153J-C RCF 1/8W 15K 5% ATS
R109 4701-104J-C RCF 1/8W 100K 5% ATS
R110 4701-222J-C RCF 1/8W 2.2K 5% ATS
Reference No. Part No. Description
