5
REAR PANEL / FRONT PANEL
REAR PANEL
FRONT PANEL
1. LINE OUT
2. DIGITAL OUT
3. NAD LINK
4. AC LINE CORD
1. POWER ON / OFF
2. DISC DRAWER
3. DISPLAY
4. OPEN
5. PLAY / PAUSE
6. TIME
7. STOP
8. REPEAT
9. RANDOM
10. SCAN Back ( ) / Forward ( )
11. SKIP Back ( ) / Forward ( )
