NAD C 541 - Integrated Circuits (ICs)

R418,R419 4701-272J-C RCF 1/8W 2.7K 5% ATS
R420-R427 4701-472J-C RCF 1/8W 4.7K 5% ATS
R428 4701-561J-C RCF 1/8W 560R 5% ATS
R501,R502 4701-241J-C RCF 1/8W 240R 5% ATS
R503,R504 4701-222J-C RCF 1/8W 2.2K 5% ATS
R517,R518,R520 4701-471J-C RCF 1/8W 470R 5% ATS
R523 4701-473J-C RCF 1/8W 47K 5% ATS
R701,R702 4701-472J-C RCF 1/8W 4.7K 5% ATS
R702 4701-472J-C RCF 1/8W 4.7K 5% ATS
ICS
U101 3130-6710-0 IC LA9240 ASP FOR CD QIP64E
U201 3130-6720-0 IC LA6541D 4-CHANNEL BTL DRIVER DIP30SLF
U301 3130-6700-0 IC LC78621ED DSP FOR CD QIP80E
U302 3131-9380-0 IC PCM1732 HDCD D/A CONVERTER
U305, U306 3130-9340-0 IC OPA2604 OPAMP DIP8 BURR-BROWN
U401 3130-9330-1 IC LC866008C MICRO MASK QFP64 SANYO
U402 3130-9320-0 IC NADLINK (MASKED) MICROCONTROLLER
U403 3130-4160-0 IC TC74HC00 NAND GATE
U501, U506 3130-2020-3 IC 7805 REG 5V 1.5A
U502 3130-5610-0 IC LM317T+ADJ REGULATOR
U503 3130-5620-0 IC LM337T-ADJ REGULATOR
U507 3130-2790-1 IC NJM7808FA +8V REG TO-220F
U701 3130-6560-0 IC LB1641 MOTOR DRIVER
26
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF- Carbon Film.
Reference No. Part No. Description
