NAD C 558 User Manual

MODEL NAD C558
Nominal speed 33/45 rpm, manual speed change (78 rpm possible with special pulley)
Speed variance 33rpm: ± < 0.50%, 45rpm: ± < 0.45%
Wow and utter 33rpm: ± < 0.15%, 45rpm: ± < 0.15%
Signal to noise S/N Ratio (mechanical noise): - 40 dB S/N Ration (electrical noise): -68 dB
Downforce range 0 - 30 mN
0 - 3.0 grams
Supplied counterweight system Counterweight (black) for cartridges 5 - 12 g
Eective tonearm mass 9.5 g
Eective tonearm length 230 mm
Overhang 18 mm
Power consumption 5 W max/ 0.3W standby
Voltage Universal swith mode power supply 15 V DC/0,8 A, 100-240 V AC, 47 - 63Hz
Dimensions (W x H x D) 435 x 340 x 125mm
Weight (without box) 5,5 kg (turntable)
1,74 kg (platter)
Weight (with box) 8 kg
ORTOFON OM 10 CARTRIDGE TECHNICAL DATA
Frequency range 20-22.000Hz
Channel separation 22dB/1kHz
Output voltage 4mV
Recommended load impedance 47kohms/amplier connection – MM-input
Compliance/stylus type 20µm/mN – elliptical
Recommended tracking force 15mN
Weight 5g
REFERENCE
SPECIFICATIONS
10
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

NAD C 558 Specifications

General

Type	Direct drive audio turntable
Operation	Manual
Product color	Black
Nominal speeds	33, 45 RPM
Output voltage	4 mV
Turntable speeds	33 RPM
Channel separation	22 dB
Signal-to-Noise Ratio (SNR)	68 dB
Frequency range	20 - 22000 Hz
Package weight	8000 g
AC adapter frequency	47/63 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.8 A
AC adapter output voltage	15 V
Power consumption (standby)	0.3 W
Power consumption (typical)	5 W
USB ports quantity	-

Weight and Dimensions

Depth	125 mm
Width	435 mm
Height	340 mm
Weight	5500 g
