NAD C 558 User Manual

Dear Music Lover,
Congratulations and thank you for choosing NAD Products. Your NAD C558
turntable has been handcrafted and rigorously tested by skilled technicians
to give you years of enjoyable, trouble free service.
Please contact your dealer if you require additional assistance.
The C558 incorporates an array of features that contribute to its
audiophile performance:
1 Proprietary ultralow noise AC motor and high precision frequency DC-
driven AC generator for speed stability. The motor is xed on the main
chassis. The tonearm and platter are mounted on a separate suspended
MDF chassis.
2 The platter with TPE damping and felt mat sits on top of a belt-holding
sub- platter. The platter is constructed from an aluminum magnesium
alloy sitting on a brass bearing.
3 The tonearm construction is a combination of conical carbon bre
tube, sandwich aluminium headshell, cardan bearing in horizontal axle
with hardened tips sitting in zircon bowl and ABEC7 ballraces in vertical
axle. The counterweight is damped with thermo-plastic elastomer (TPE)
damping pad.
4 All key features for cartridge alignment and adjustability are available
on the tonearm - VTA/SRA, VTF, azimuth, anti-skate, and a slotted
aluminum headshell for overhang and oset angle.
5 The conical thermo-plastic elastomers (TPE) suspension system
dampens vibrations.
6 A low-prole sandwich oating chassis made of MDF is what gives this
table a “superat” silhouette.
IMPORTANT
Your turntable was shipped partially disassembled in order to avoid
damage to sensitive parts. Please check immediately to make sure that
neither the packaging nor the device was damaged in transit. If you
are missing parts or if the unit is damaged, please do not operate and
contact your dealer.
PLEASE DO YOUR PART TO HELP PROTECT THE ENVIRONMENT
DISPOSAL OF PACKAGING MATERIAL
NAD packaging is carefully designed to protect your component from
damage in transit and you are strongly urged to keep the original
packaging in order to safely ship or otherwise transport your
turntable in the future.
However, the packaging materials were chosen to be environmentally
friendly, so if you must discard the packaging, please recycle.
INTRODUCTION
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .........................2
INTRODUCTION
DISPOSAL OF PACKAGING MATERIAL .................................3
IDENTIFICATION OF CONTROLS
FEATURES AND CONNECTIONS ...................................4
SETUP
ASSEMBLY AND INSTALLATION ...................................5
TRANSPORT SCREWS .................................................5
PLATTER, SUBPLATTER AND DRIVE BELT INSTALLATION .............5
ADJUSTING THE PULLEY HEIGHT .....................................5
TONEARM ASSEMBLY .................................................5
LEVELING THE TURNTABLE ...........................................8
USING THE CLAMP, STARTING THE MOTOR, ...........................8
CHANGING THE SPEED ...............................................8
REFERENCE
TROUBLESHOOTING .............................................9
SERVICE ..............................................................9
WARRANTY ...........................................................9
SPECIFICATIONS ................................................10
3
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

NAD C 558 Specifications

General

Type	Direct drive audio turntable
Operation	Manual
Product color	Black
Nominal speeds	33, 45 RPM
Output voltage	4 mV
Turntable speeds	33 RPM
Channel separation	22 dB
Signal-to-Noise Ratio (SNR)	68 dB
Frequency range	20 - 22000 Hz
Package weight	8000 g
AC adapter frequency	47/63 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.8 A
AC adapter output voltage	15 V
Power consumption (standby)	0.3 W
Power consumption (typical)	5 W
USB ports quantity	-

Weight and Dimensions

Depth	125 mm
Width	435 mm
Height	340 mm
Weight	5500 g
