CONDITION POSSIBLE CAUSES
The platter doesn’t turn although the unit
is switched on
The unit is not connected to the mains power supply (the buildings electrical system).
No mains power is being delivered at the socket.
The drive belt is not tted properly or has slipped o.
No signal through one or both channels: No signal contact from the cartridge to the internal tonearm wiring; or from that to the arm lead; or
from that to the phono box; or between that and the amplier. This could be due to a faulty plug,
broken wire or loose solder joint in the plug/socket connection.
Phono input not selected at amplier.
Amplier not switched on.
Amplier or speakers are defective or muted.
No connection to the loudspeakers.
Strong hum on phono input: No ground connection from cartridge or arm or arm cable to amplier, or ground loop.
Distorted or inconsistent sound from one
or both channels:
Turntable is connected to wrong input of amplier, or MM/MC switch is incorrectly set. Needle or
cantilever damaged. Wrong rpm; drive belt overstretched or dirty; platter bearing needs lubrication
or is dirty or damaged.
REFERENCE
TROUBLESHOOTING
SERVICE
Should you encounter a problem that you are not able to identify or
alleviate despite the above information, please contact your dealer for
further advice. Only when the problem cannot be resolved should the unit
be sent to the responsible distributor in your country.
Guarantee repairs will only be eected if the unit is returned in appropriate
packaging. For this reason we recommend keeping the original packaging.
Never return a turntable without making sure that is it properly
disassembled and correctly packaged in the original packaging according
to the supplied diagram. Please: Remove the feet, counterweight, platter,
cartridge and belt and pack them separately. Fit the cartridge protection
cap. Insert the transport lock for the tonearm prior to carefully packaging
the turntable.
WARRANTY
The manufacturer accepts no responsibility for damage caused by failing to
adhere to these instructions for use and/or by transportation without the
original packaging. Modication or change to any part of the product by
unauthorized persons releases the manufacturer from any liability over and
above the lawful rights of the customer.
9
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NAD C 558 and is the answer not in the manual?

NAD C 558 Specifications

General IconGeneral
TypeDirect drive audio turntable
OperationManual
Product colorBlack
Nominal speeds33, 45 RPM
Output voltage4 mV
Turntable speeds33 RPM
Channel separation22 dB
Signal-to-Noise Ratio (SNR)68 dB
Frequency range20 - 22000 Hz
Package weight8000 g
AC adapter frequency47/63 Hz
AC adapter input voltage100 - 240 V
AC adapter output current0.8 A
AC adapter output voltage15 V
Power consumption (standby)0.3 W
Power consumption (typical)5 W
USB ports quantity-
Weight and Dimensions IconWeight and Dimensions
Depth125 mm
Width435 mm
Height340 mm
Weight5500 g
