NAD C326BEE - C 326 BEE Technical Specifications; Preamplifier Section Specifications; Power Amplifier Section Specifications; Overall and Physical Specifications

PREAMPLIFIER SECTION
Line level input, Pre OUT
THD (2V in 2V out,
CCIF IMD, DIM 100) >0.004% (ref. 20Hz – 20kHz)
Signal/Noise ratio IHF >100dB (A-weighted, ref. 500mV)
>108dB (A-weighted, ref. 2V, Volume maximum)
>92dB (A-weighted, ref. 100mV in 100mV out - unity gain)
Channel separation 1kHz >80dB
10kHz >70dB
Input impedance (R and C) 100kΩ+ 320pF
Maximum input signal >8V rms (ref. 0.1 THD)
Output impedance Pre out 75Ω
Tape out Source Z + 1kHz
Input sensitivity 159mV (ref. 500mV out)
Frequency response ± 0.1dB (ref. 20Hz - 20kHz, Tone defeat ON)
± 0.5dB (ref. 20Hz - 20kHz, Tone defeat OFF)
Maximum voltage output
IHF load >10V (ref. 0.03% THD)
600 ohms load >10V (ref. 0.03% THD)
Tone controls
Treble ± 5dB at 10kHz
Bass ± 8dB at 100Hz
POWER AMPLIFER SECTION
Main IN, Speaker OUT
Continuous output power
into 8Ω and 4Ω (Stereo) >50W (ref. rated THD, 20Hz-20kHz, both channels driven)
Rated THD (CCIF IMD, DIM 100) <0.009% (ref. 20Hz - 20kHz)
Clipping power >65W (ref. 1kHz 1% THD)
IHF dynamic power
8Ω 100W
4Ω 150W
2Ω 200W
Peak output current >20A (ref. 1Ω, 1ms)
Signal/Noise ratio >100dB (A-weighted, ref. 1W)
>117dB (A-weighted, ref. 150W)
Damping factor >100 (ref. 8Ω, 50Hz and 1kHz)
Frequency response ± 0.1dB (ref. 20Hz - 20kHz)
3Hz – 70kHz (ref. -3dB)
Input impedance 20kΩ + 1nF
Input sensitivity 630mV (ref. rated power)
Voltage gain 29dB
Headphone output impedance 68Ω
> SPECIFICATIONS
C 326BEE Stereo Integrated Amplifier
Channel separation 1kHz >80dB
10kHz >70dB
Trigger Out
Output resistance <100Ω
Output current 50mA
Output voltage +12V
OVERALL SPECIFICATIONS
CD IN, Speaker OUT
THD (250mW to rated power,
CCIF IMD, DIM 100) <0.009% (ref. 20Hz - 20kHz)
Signal/Noise ratio >94dB (A-weighted, ref. 1W)
>110dB (A-weighted, ref. 50W,
volume set for 2V input)
Frequency response ± 0.2dB (ref. 20Hz - 20kHz,
Tone Defeat ON)
10Hz – 65kHz (ref. -3dB)
Channel separation 1kHz >80dB
10kHz >70dB
Power Consumption
Rated power 290W (ref. 230V AC 50 Hz;
120V AC 60Hz)
Standby power <1W
Idle power <35W
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) Net 435 x 100 x 286mm
17 1/8” x 4” x 11 1/4”
Gross* 435 x 116 x 332mm
17 1/8” x 12 1/2” x 13”
Net weight 15.21 lbs (6.9 kg)
Shipping
weight 20 lbs (9.1 kg)
* Gross dimensions include volume knob / speaker terminals /
connectors / feet. Note: Installers should allow a minimum clearance
of 2- 4 inches for wire/cable management.
