NAD C521 Service Manual

22
Reference No. Part No. Description
DISPLAY ASSEMBLY
PCB BOARD
1000 PCB-N0980C-DISP DISPLAY ASSEMBLY
LCD
M501 2460-1340-1 LCD DISPLAY
BACKLIGHT
M502 2450-1146-0 EL BACKLIGHT
IR SENSOR
M113 4816-043T-3 IR SENSOR PIC-26043TM2 KODENSHI
KEYBOARD ASSEMBLY
PC BOARD
2000 PCB-N0980C-KEY KEYBOARD ASSEMBLY
SWITCHES
M101-M104, M106 5200-3538-0 SWITCH, TACT SKHHBY 7MM HIGH
M108-M112 5200-3538-0 SWITCH, TACT SKHHBY 7MM HIGH
LIVE ASSEMBLY
PC BOARD
3000 *AH PCB-N0980C-LIVE LIVE ASSEMBLY
3000 *C PCB-N0981C-LIVE LIVE ASSEMBLY
CAPACITOR
C800 8910-0049-0 CAP400V 4700P DE7150F472MVA1KC
POWER SWITCH
M802 5200-3151-0-01 POWER SWITCH
TRANSFORMER
M810 *C 1806-2170-0 EMI FILTER TLN12UA 150W3R0
TRANSFORMER ASSEMBLY
4000 *AH PCB-N0980C-PWR TRANSFORMER ASSEMBLY
4000 *C PCB-N0981C-PWR TRANSFORMER ASSEMBLY
TRANSFORMER
M500 1806-2194-0 EI-57 TRANSFORMER 740 AC3
FUSE ASSEMBLY
FUSES
M502-M504 *AH 5120-0020-0 FU T1A 250V UL/CSA 5X20MM
M502-M504 *C 5120-0018-0 FU T1A 250V SEMKO/UDE 5X20MM
M505 *AH 5120-0052-0 FUSE T1.6A 250V 5X20MM UL/CSA
M505 *C 5120-0050-0 FUSE T1.6A/250V 5X20MM SEMKO/VDE
MAIN
ASSEMBLY
PC BOARD
5000 PCB-N0980C-MAIN MAIN ASSEMBLY
ELECTRICAL PARTS LIST
