28
ITEM Part No. Description Qty
1 4102-6101-0 RUBBER CUSHION (HARD) 2
2 4102-6102-0 RUBBER CUSHION (SOFT) 2
3 4102-6103-0 BASE 1
4 4102-6104-0 TRAY 1
5 4102-6105-0 CDM MOUNTING BASE 1
6 4102-6106-0 MAGNET HOLDER 1
7 4102-6107-0 SLIDE GEAR 1
8 4102-6108-0 PULLEY GEAR 1
9 4102-6109-0 DRIVE GEAR 1
10 4102-6110-0 PULLEY MOTOR 1
11 4102-6111-0 SQUARE BELT 1
12 4102-6112-0 MAGNET 1
13 4102-6113-0 LOADING MOTOR 1
14 4102-6114-0 SWITCH PUSH 2-1 2
15 4102-6115-0 CON JST 5P RT 1
16 4102-6116-0 MOTOR/SW.PCB 1
17 4102-6117-0 SCREW M3.0X8.0 1
18 4102-6118-0 PLATE MAGNET 1
19 4102-6213-0 LASER CD11CA-G 1
MECHANISM EXPLODED VIEW PARTS LIST
