NAD C521 Service Manual

32
ITEM Part No. Description Qty
0001 1465-5703-2 FASCIA W/SS PAINT 1
0002 1402-3781-2 STRAP 1
0003*AH 1402-3516-0 CHASSIS W/SS PAINT 1
0003*C 1402-3517-0 CHASSIS W/SS PAINT 1
0005 1402-3530-0 COVER 1
0006 2442-1000-0 POWER BUTTON 1
0007 1464-6011-3 CD DOOR W/SS PAINT 1
0008 3716-4313-0 WINDOW LENS W/SS 1
0010 2444-1201-0 BUTTON TRIO 2
0012 4111-1131-0 CD DECK 1
0013 4152-4631-0 RUBBER FOOT 14MM HIGH 4
0014 4151-9461-0 STRAIN RELIEF BUSHING 4N-4 1
0018 4152-4641-0 CUSHION FOOT 4
0019 2444-1301-1 BUTTON RACKER 2
0020 4132-6191-0 BRACKET,MTG,X'FORMER 2
0021 4152-4331-0 POWER BUTTON BEZEL 1
0022 4154-0031-0 BEZEL TRIO 2
0023 4154-0091-0 BEZEL RACKER 2
0101*AH 7009-3100-2 AC CORD 18AWGX2 SPT-2 D.INSULATED UL/CSA 1
0101*C 7009-3110-0 AC CORD SEMKO 1
0201 2900-4006-3010 M4X0.5PX6MM W/FLAT WASHER 4
0202 2954-3008-3000 T3X8MM SELF TAPPING 12
0205 2954-3008-0000 TAPPING 3X8MM B-TITE(YEL.ZN) 17
0208 2842-3367-0 METAL WASHER ID=3.3 OD=6.7 4
0209 2900-4010-3030 PH W/WASHER M4X10 BL ZN 2
0211 2904-3006-0000 SCREW M3X6 4
0218 2954-3006-0000 3X6MM B-TITE (YEL.ZN) 2
0219 2954-4010-3000 SCREW TAP-C2 BH M4X10MM BZ CROSS 4
0223 2600-4008-0973 FLAT WASHER M4X0.8X9.7 BZ 2
0224 2640-4030-0703 M4 NUT (BLK) 2
0226 2954-2006-0000 TAPPING SCREW 2X6 13
0227 2954-2608-0000 SCREW BT 2.6X8 7
0228 2950-2608-3000 SCREW PAN HEAD,B-TITE 2.6X8 BLACK 1
0304 1463-160B-0 CD TRANSIT LOCK (RED) 1
0320 4154-1931-0 DUST PROOF CUSHION 1
M500 1806-2194-0 EI-57 TRANSFORMER 740 AC3 1
U501-U503 5400-9130-0 HEAT SINK FOR 7805 2438-17 3
U506-U507 5400-9130-0 HEAT SINK FOR 7805 2438-17 2
EXPLODED VIEW PARTS LIST
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
