NAD C521 Service Manual

24
C370 153F-103J-5-IM CM 50V 0.01µF 5% RL 5X7
C371-C374 157D-477M-5-OY CE 470µF +-20% RL 8X13
C375,C376 157E-226M-5-IU CE 25V 22µF 20% RL 5x11
C377-C379, C382 153F-224J-5-MIB CM 50V 0.22µF 5% RL 7x5
C380, C381 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C383 157C-226M-5-IU CE 10V 22µF 20% RL 5x11
C384 150F-102K-5-IF CC 50V 1000pF 10% RL 5X3
C385 150F-222K-5-LF CC 50V 2200pF 10% RL
C386, C401 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C402 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
C403, C405 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C407 157D-108M-5-S9 CE 16V 1000µF 20% RL 10X20
C408 157E-226M-5-IU CE 25V 22µF 20% RL 5x11
C410 157B-106M-5-EI CE 6.3V 10µF 20% RL 3x5
C411 153F-103J-5-IM CM 50V 0.01µF 5% RL 5X7
C412-C417 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C418 157E-106M-5-IU CE 25V 10µF 20% RL 5x11
C440-C443 150F-103K-2-FC CC 50V 0.01µF 10% AT
C501-C505 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C506, C507 157E-228M-5-X9 CE 25V 2200µF 20% RL 12.5X20
C508 157C-108M-5-S5 CE 10V 1000µF 20% RL 10X16
C511 157C-227M-5-KW CE 10V 220µF 20% RL 6x12
C512, C513 157D-108M-5-S9 CE 16V 1000µF 20% RL 10X20
C518 157E-107M-5-KW CE 25V 100µF 20% RL 6x12
C521 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C522 157D-107M-5-IU CE 16V 100µF 20% RL 5x11
C523 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11
C524 153F-223J-5-LQ CM 50V 0.022µF 5% RL 6.5X9
C525 157D-477M-5-OY CE 470µF +-20% RL 8X13
C526 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C527 157C-108M-5-S5 CE 10V 1000µF 20% RL 10X16
C528 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C529 157D-338M-5-W@ CE 16V 3300µF 20% RL 12X26
C532 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C533 157C-477M-5-OW CE 10V 470µF 20% RL 8x12
C534, C535 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C540-C543 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C701 153F-103J-5-IM CM 50V 0.01µ 5% RL 5X7
C702 157C-476M-5-IU CE 10V 47µF 20% RL 5x11
C703 150F-104K-5-II CC 50V 0.1µF 10% RL 5X5
C704 153F-103J-5-IM CM 50V 0.01µ 5% RL 5X7
C710 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
DIODES
D101, D401-D402 4804-1480-2 DIODE 1N4148 AT
D403 4837-3V31-2 DZ 1/2W 3.1-3.5V ROHM AT
D409, D411 4804-1480-2 DIODE 1N4148 AT
D501-D504 4804-0010-2 DIODE 1N4001 AT
D505 4840-1140-0 ZD 1.3W 3.3V 5% AT
D506,D514-D517 4804-0010-2 DIODE 1N4001 AT
D707 4804-1480-2 DIODE 1N4148 AT
COILS
J510, L101 1801-100K-M COIL 10µH 10% BL7.0
L301 1802-0450-0 DIGITAL COIL 015-910-27BB
CRYSTAL
M301, M302 2300-0110-0 CRYSTAL 16.9344 MHZ
Reference No. Part No. Description
