ITEM Part No. Description Qty

1 4102-6214-0 ASSY PICKUP LASER P101N 1

2 4102-6215-0 ASSY MOTOR 6.0V SPINDLE 1

3 4102-6216-0 ASSY MOTOR SLED 6.0V 1

4 4102-6217-0 CHASSIS 1

5 4102-6218-0 COVER GEAR 1

6 4102-6219-0 SHAFT SLIDE 1

7 4102-6220-0 GEAR MIDDLE 1

8 4102-6221-0 GEAR DRIVE 1

9 4102-6222-0 SWITCH LEAF(PWB MOTOR) 1

10 4102-6223-0 PLUG 6P 1

11 4102-6224-0 PWB MOTOR 1

12 4102-6225-0 SCREW PAN PCS 2x3 4

13 4102-6226-0 SCREW SELF-TAPING FLT 2.6x6 2

EXPLODED VIEW PARTS LIST OF LASER CD11CA-G

NAD C521 Service Manual
