NAD M25 C - Page 37

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
Q328 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q329 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q330 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q331 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q332 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q333 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q334 Transistor 2SD667-AWC 31-00667-00 TO92/100/ECB
R301 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R302 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R303 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R304 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R305 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R306 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R307 Metal Film Resistor 510Ω, 1/6W, 5% 07-20511-00 AX/.200X.080/.031
R308 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R309 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R310 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R311 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R312 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R313 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R314 Metal Film Resistor 330Ω, 1/6W, 5% 07-20331-00 AX/.200X.080/.031
R315 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R316 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R317 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R318 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R319 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R320 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R321 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R322 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R323 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R324 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R325 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R326 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R327 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R328 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R329 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R330 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R331 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R332 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R333 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R334 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R335 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R336 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R337 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R338 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R339 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R340 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R341 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R342 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R343 Metal Film Resistor 56Ω, 1/6W, 5% 07-20560-00 AX/.200X.080/.031
R344 Metal Film Resistor 120Ω, 1/6W, 5% 07-20121-00 AX/.200X.080/.031
R345 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R346 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R347 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R348 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R349 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R350 Metal Film Resistor 360Ω, 1/6W, 5% 07-20361-00 AX/.200X.080/.031
C301
ALU Electrolytic
Capacitor
47uF/16V, 20%, 105
06-47011-00 CPCYL1/D.200/LS.200/.031
RESISTOR
CAPACTIOR
ELECTRICAL PARTS LIST
-37-
