NAD M25 C - Page 38

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
P302A Housing 1.0-11-16PS 13-21016-06
BLKCON.079/VH/TM1SQ/W.200/
16
D401 Zener Diode 24V, 1/2W 33-12400-06 DAX/.300X.080/.031
D402 Zener Diode 24V, 1/2W 33-12400-06 DAX/.300X.080/.031
D403 Zener Diode 24V, 1/2W 33-12400-06 DAX/.300X.080/.031
D404 Zener Diode 24V, 1/2W 33-12400-06 DAX/.300X.080/.031
R401 Metal Film Resistor 27KΩ, 1/6W, 1% 07-22702-00 AX/.200X.080/.031
R402 Metal Film Resistor 27KΩ, 1/6W, 1% 07-22702-00 AX/.200X.080/.031
R403 Metal Film Resistor 27KΩ, 1/6W, 1% 07-22702-00 AX/.200X.080/.031
R404 Metal Film Resistor 27KΩ, 1/6W, 1% 07-22702-00 AX/.200X.080/.031
R405 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R406 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R407 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R408 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R409 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R410 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R411 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R412 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R413 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
C401
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C402
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C403
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C404
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
P401B HOUSING 12PIN2.0-C 13-22012-00
S401 SWITCH SSSU142NA1 11-05402-00 SLIDESWITCHES/SSSU121700
S402 SWITCH SSSU122NA1 11-05202-10 SLIDESWITCHES/SSSU141500
J401 12V TRIG IN PY301-030-100 17-07001-00
D501 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
C501
High Voltage Ceramic
Capacitor
220nF, 275V, ±10% 25-22422-04
RV501 Inrush Current Limiter 0.5R030
07-70059-00
RAD/1.110X.180/LS.300/.047
W501 Jumper 7.5mm 21-06750-00 7.5mm
W502 Jumper 10mm 21-06101-00 10mm
W505(C) Jumper 7.5mm 21-10750-00 7.5mm
W503(AH) Jumper 15mm 21-10151-00 15mm
W504(AH) Jumper 15mm 21-10151-00 15mm
TR501
STANDBY
TRANSFORMER
TD030-E102D 18-35003-00
TR502
CURRENT
TRANSFORMER
DHCT3 10A/4mA 18-52510-00
CONNECTORS
P/N 01-52504-00 PCB4 BOARD ( TRIGGER)
DIODE
RESISTOR
CAPACTIOR
CONNECTOR
DIODE
SWITCH
AH P/N: 01-52505-10 C/BC P/N:01-52505-20 PCB5 BOARD ( STANDBY)
CAPACTIOR
INRUSH LIMITER
JUMPER
TRANSFORMER
RELAY
ELECTRICAL PARTS LIST
-38-
