NAD T 751 - Electrical Parts List - Components; Capacitors, Diodes, Connectors, Coils, Crystal, Transistors; Resistors List (Part 1)

C176 157C-107M-5-IU CE 10V 100µF 20% RL 5x11
C179-C180, C183-C184 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C193-C194, C198 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C199 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C1101 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1102 15FF-224Z-J-BD CC 50V 0.22µF +80/-20% 0805
C1104 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1105 15FF-224Z-J-BD CC 50V 0.22µF +80/-20% 0805
C1106-C1107 157D-226M-5-GM CE 16V 22µF 20% RL 4x7
C1112-C1114 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C1115 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C1116 157E-105M-5-EI CE 25V 1µF 20% RL 3x5
C1117 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1118 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C1119-C1121 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1122-C1123, C1131-C1134 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
C1135 150F-100J-J-BD CC 50V 10pF 5% 0805 1.2x2.0
C1136-C1137 150F-104K-J-BD CC 50V 0.1µF 10% 0805 1.2x2.0
DIODE
D101 4840-0490-0 BRIDGE RECTIFIER RB152 100V 1.5A
WAFER
J101A 2102-101S-004 WAFER 10P P2.5 ST.(COULOMB)
CONNECTORS
J203B 2101-1581-0 FLEXIBLE CONN. 35P P1.25 SIDE ENTRY
J601B 2102-121S-004 12P ST.WAFER P=2.5 COULOMB
J604B 2102-031S-004 3 PIN ST. WAFER P=2.5 COULOMB
COILS
L101-L104 1801-100K-M COIL 10µH 10% BL7.0
CRYSTAL
M101 2300-3060-0 X'TAL 12.288MHZ +/-20PPM HCMOS/TTL
OSCILLATOR
TRANSISTOR
Q101 485C-114E-5 TR DTC114ES
RESISTORS
R101-R103 4720-103J-J RMG 1/10W 10K 5% 0805
R104 4720-680J-J RMG 1/10W 68R 5% 0805
R105-R109 4720-103J-J RMG 1/10W 10K 5% 0805
R110 4707-103C-5-8 RCFA 1/2W 10K 2% RL 8 9P SIP 4609x-101-103
R111-R112 4720-103J-J RMG 1/10W 10K 5% 0805
R113 4720-473J-J RMG 1/10W 47K 5% 0805
R114 4720-821J-J RMG 1/10W 820R 5% 0805
R115 4720-750J-J RMG 1/10W 75R 5% 0805
R116 4720-473J-J RMG 1/10W 47K 5% 0805
R117 4720-821J-J RMG 1/10W 820R 5% 0805
R118 4720-750J-J RMG 1/10W 75R 5% 0805
R119 4720-000J-J RMG 1/10W 0R 5% 0805
R122 4720-151J-J RMG 1/10W 150R 5% 0805
R123 4720-103J-J RMG 1/10W 10K 5% 0805
R125 4720-151J-J RMG 1/10W 150R 5% 0805
R126 4720-103J-J RMG 1/10W 10K 5% 0805
R127 4720-104J-J RMG 1/10W 100K 5% 0805
R129 4720-000J-J RMG 1/10W 0R 5% 0805
48
Reference No. Part No. Description
