NAD T 751 - Electrical Parts List - Resistors and ICs; Resistors List (Part 2); Integrated Circuits (ICs) List

49
R130 4720-151J-J RMG 1/10W 150R 5% 0805
R131 4720-103J-J RMG 1/10W 10K 5% 0805
R133 4720-151J-J RMG 1/10W 150R 5% 0805
R134 4720-103J-J RMG 1/10W 10K 5% 0805
R135-R136 4720-102J-J RMG 1/10W 1K 5% 0805
R137 4720-151J-J RMG 1/10W 150R 5% 0805
R138 4720-103J-J RMG 1/10W 10K 5% 0805
R139 4720-102J-J RMG 1/10W 1K 5% 0805
R140 4720-101J-J RMG 1/10W 100R 5% 0805
R150 4720-151J-J RMG 1/10W 150R 5% 0805
R155 4720-153J-J RMG 1/10W 15K 5% 0805
R156-R157 4720-103J-J RMG 1/10W 10K 5% 0805
R158 4720-151J-J RMG 1/10W 150R 5% 0805
R159 4720-153J-J RMG 1/10W 15K 5% 0805
R160-R161 4720-103J-J RMG 1/10W 10K 5% 0805
R162 4720-151J-J RMG 1/10W 150R 5% 0805
R163-R164 4720-223J-J RMG 1/10W 22K 5% 0805
R165 4720-121J-J RMG 1/10W 120R 5% 0805
R166 4720-201J-J RMG 1/10W 200R 5% 0805
R167-R168 4720-103J-J RMG 1/10W 10K 5% 0805
R169 4720-102J-J RMG 1/10W 1K 5% 0805
R171 4720-103J-J RMG 1/10W 10K 5% 0805
R172 4720-471J-J RMG 1/10W 470R 5% 0805
R173 4720-103J-J RMG 1/10W 10K 5% 0805
R181 4720-000J-J RMG 1/10W 0R 5% 0805
R184-R185 4720-104J-J RMG 1/10W 100K 5% 0805
R186, R189 4720-000J-J RMG 1/10W 0R 5% 0805
R190-R192 4720-104J-J RMG 1/10W 100K 5% 0805
R193 4720-000J-J RMG 1/10W 0R 5% 0805
R194 4720-335J-J RMG 1/10W 3.3M 5% 0805
ICs
U101 3131-3980-0 IC 74HC153 QUAD 4-INPUT MUx SOP16
U102 3131-3870-0 IC 74HC157 QUAD 2-INPUT MUx SO16
U103 3131-3700-0 IC CS5331A 18BIT A/D CONVERTER CRYSTAL
U104 3130-9560-0 NJM5532 IC 'DIP8' ELE-IC029
U105 3131-3720-0 IC CS4926 DSP CRYSTAL
U106-U107 3130-8980-0 IC 74HC574 8x D-TYPE LATCHES
U108 3131-9320-0 IC AT27C020-70 256Kx8 OTP
U109 3130-9560-0 NJM5532 IC 'DIP8' ELE-IC029
U110 3130-8890-0 IC CS8414 DIR 96KHZ 24BIT
U111-U113 3131-3710-0 IC CS4340 D/A CONVERTER CRYSTAL
U114 3131-9100-0 IC 74HCU04 HEX INVERTERS (SOP)
U115 3130-6590-0 IC 74HC74 DUAL D-TYPE FLIP-FLOP
U116 3130-9560-0 NJM5532 IC 'DIP8' ELE-IC029
U117 3130-6590-0 IC 74HC74 DUAL D-TYPE FLIP-FLOP
U118, U119 3131-9050-0 IC 74HC00 QUAD 2I/P NAND GATE SOP
U120 3130-6590-0 IC 74HC74 DUAL D-TYPE FLIP-FLOP
U121 3130-5610-0 IC LM317T+ADJ REGULATOR
U123, U125 3130-2020-2 IC 7805 REG 5V
U131, U134 3130-9560-0 NJM5532 IC 'DIP8' ELE-IC029
FRONT
AMP BOARD
ASSEMBLY
PC BOARD
2401 PCB-N0910C-AMP1 PCB ASSY POWER AMP L/R/C N091XC
CAPACITORS
C501-C502 157D-476M-5-IM CE 16V 47µF 20% RL 5x7
Reference No. Part No. Description
