NAD T 751 - Page 43

53
C803-C804 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C805-C806 150F-020C-5-GG CC 50V 2pF 0.25pF RL 4x4
C807-C808 150F-471K-5-GG CC 50V 470pF 10% RL 4x4
C809-C810 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C811-C812 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C813-C814 150F-181K-5-GG CC 50V 180pF 10% RL 4x4
C815-C816 150F-070D-5-GG CC 50V 7pF 0.5pF RL 4x4
C817-C820 157F-106M-5-GM CE 50V 10µF 20% RL 4x7
C821-C822 150F-223Z-5-UG CC 50V 0.022µF +80/-20% RL 11x4
C823-C824 153F-104J-5-QUN CM 50V 0.1µF RL (9x11) POLYESTER
C829-C830 157I-477M-5-X& CE 63V 470µF 20% RL 12.5x25
C831-C832 150F-151K-2-FC CC 50V 150pF 10% AT 3.5x2
C833 150F-223Z-5-UG CC 50V 0.022µF +80/-20% RL 11x4
C835-C836 150F-151K-2-FC CC 50V 150pF 10% AT 3.5x2
DIODES
D801-D802 4804-0040-1 DIODE 1N4004 AL
D803-D805 4804-1480-C DIODE 1N4148 ATS
WAFERS
J602B 2102-031S-004 3 PIN ST. WAFER P=2.5 COULOMB
JP801-JP802 2113-1160-0 WAFER 2P ST. P=2.5 NH (JST)
CONNECTOR WIRES
J801A 7708-1150-3004 CONN.ASSY AWG24 8P P2.5 L=150
J802A 7710-1200-3004 CONN ASSY 10P P2.5 L200 AWG24
RELAY
M801 4500-0910-0 RELAY 24VDC,125VA,3A OSA-SS-224DM3 OEG
TRANSISTORS
Q801-Q806 4860-0190-5 TR 2SC1845 (F.E) RL
Q807-Q808 4860-1590-5 TR 2SC1740S (R) HFE180-390
Q809-Q812 485A-949O-5 TR 2SA949-O HFE 70-140 TOSHIBA
Q813-Q814 485C-5171-5 TR 2SC5171 HFE 100-320
Q815-Q816 485A-949O-5 TR 2SA949-O HFE 70-140 TOSHIBA
Q817-Q820 485C-2229-5 TR 2SC2229-0 HFE 70-140 TOSHIBA
Q821-Q822 4860-1220-5 TR 2SC3421 (0,Y) RL TSB
Q823-Q824 485A-1930-5 TR 2SA1930 HFE 100-320
Q825-Q826 4860-5210-5 TR 2SC5198-0 HFE 80-160 70W TOSHIBA
Q827-Q828 4860-5220-5 TR 2SA1941-0 HFE 80-160 70W TOSHIBA
Q829-Q830 4860-0190-5 TR 2SC1845 (F.E) RL
Q831 485C-123J-5 TR DTC123JSA ROHM
RESISTORS
R803-R804 4701-273J-C RCF 1/8W 27K 5% ATS
R805-R806 4701-471J-C RCF 1/8W 470R 5% ATS
R807-R808 4701-180J-C RCF 1/8W 18R 5% ATS
R809-R810 4701-562J-C RCF 1/8W 5.6K 5% ATS
R811,R812 4701-180J-C RCF 1/8W 18R 5% ATS
R813-R816 4701-102J-C RCF 1/8W 1K 5% ATS
R817-R818 4701-104J-C RCF 1/8W 100K 5% ATS
R819-R822 4717-680J-1 RMF 1/2W 68R 5% AL
R823-R824 4701-273J-C RCF 1/8W 27K 5% ATS
R825-R826 4701-821J-C RCF 1/8W 820R 5% ATS
R827-R828 4701-560J-C RCF 1/8W 56R 5% ATS
R829-R830 4701-183J-C RCF 1/8W 18K 5% ATS
R831-R832 4701-512J-C RCF 1/8W 5.1K 5% ATS
R833-R834 4701-183J-C RCF 1/8W 18K 5% ATS
Reference No. Part No. Description
