NAD T 751 - Page 44

54
R835-R836 4701-332J-C RCF 1/8W 3.3K 5% ATS
R837-R838 4715-331A-2 RMF 1/4W 330R 1% AT
R839-R840 4701-471J-C RCF 1/8W 470R 5% ATS
R841-R844 4717-2R2J-2 RMF 1/2W 2.2R 5% AT
R845-R846 4701-271J-C RCF 1/8W 270R 5% ATS
R847-R848 4701-104J-C RCF 1/8W 100K 5% ATS
R849-R850 4717-560J-2 RMF 1/2W 56R 5% AT
R851-R852 4717-680J-1 RMF 1/2W 68R 5% AL
R853-R854 474B-R22K-5-02 RWR 5W 0.22R x2 10% RL
R855-R856 4707-272J-2 RCF 1/2W 2.7K 5% AT
R857-R858 4718-8R2J-2-x RMF 1W 8.2R 5% AT
R859-R860 4717-2R2J-2 RMF 1/2W 2.2R 5% AT
R861-R862 4701-333J-C RCF 1/8W 33K 5% ATS
R863-R864 4701-473J-C RCF 1/8W 47K 5% ATS
R865-R866 4701-223J-C RCF 1/8W 22K 5% ATS
SEMI-FIXED RESISTORS
R867-R868 4756-2026-3-03 SVR 2.2K H3 7x7.6 R0615C
AUDIO BOARD
ASSEMBLY
PC BOARD
1201 PCB-N0910C-AUD PCB ASSY AUDIO N091xC
JACKS
1202, 1203 2113-1805-0 6P RCA JACK R/W GOLD W/SHIELD
SWITCH
1204 5200-3171-0-01 DPDT SLIDE SW.SK-22F28-G9TS
CAPACITORS
C301-C302 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C303 157D-107M-5-IU CE 16V 100µF 20% RL 5x11
C304 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C305-C306 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C319-C322, C325-C332 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x2
C333-C334, C337-C338 157D-335M-5-II CE 16V 3.3µF 20% RL 5x5
SOCKETS
J707B, J711B 2101-1801-0 SOCKET (PCB/PCB) 10P P2.0
TRANSISTORS
Q302 485A-114E-5 TR DTA114ESA ROHM
Q303 485C-144E-5 TR DTC144ES ROHM
RESISTORS
R302-R303 4701-102J-C RCF 1/8W 1K 5% ATS
R304 4701-470J-C RCF 1/8W 47R 5% ATS
R305 4701-103J-C RCF 1/8W 10K 5% ATS
R331 4701-331J-C RCF 1/8W 330R 5% ATS
R332 4701-105J-C RCF 1/8W 1M 5% ATS
R333 4701-331J-C RCF 1/8W 330R 5% ATS
R334 4701-105J-C RCF 1/8W 1M 5% ATS
R335 4701-331J-C RCF 1/8W 330R 5% ATS
R336 4701-105J-C RCF 1/8W 1M 5% ATS
R337 4701-331J-C RCF 1/8W 330R 5% ATS
R338 4701-105J-C RCF 1/8W 1M 5% ATS
R339 4701-222J-C RCF 1/8W 2.2K 5% ATS
R340 4701-105J-C RCF 1/8W 1M 5% ATS
R341 4701-222J-C RCF 1/8W 2.2K 5% ATS
Reference No. Part No. Description
