NAD T 751 - Page 45

55
R342 4701-105J-C RCF 1/8W 1M 5% ATS
R343 4701-222J-C RCF 1/8W 2.2K 5% ATS
R344 4701-105J-C RCF 1/8W 1M 5% ATS
R345 4701-222J-C RCF 1/8W 2.2K 5% ATS
R346 4701-105J-C RCF 1/8W 1M 5% ATS
R347 4701-222J-C RCF 1/8W 2.2K 5% ATS
R348 4701-105J-C RCF 1/8W 1M 5% ATS
R349 4701-222J-C RCF 1/8W 2.2K 5% ATS
R350 4701-105J-C RCF 1/8W 1M 5% ATS
R351 4701-222J-C RCF 1/8W 2.2K 5% ATS
R352 4701-105J-C RCF 1/8W 1M 5% ATS
R353 4701-222J-C RCF 1/8W 2.2K 5% ATS
R354 4701-105J-C RCF 1/8W 1M 5% ATS
R355 4701-472J-C RCF 1/8W 4.7K 5% ATS
ICs
U301 3131-3570-0 IC TC9273N-004 ANALOG SWITCH ARRAY
U302 3130-5220-0 IC 4066 QUAD BILATERAL SWITCH
DIGITAL
BOARD ASSEMBLY
PC BOARD
1601 PCB-N0910C-DIG PCB ASSY DIGITAL N091XC
TOS-LINK
1602 4811-F32R-3 LIGHT Rx UNIT GPIF32R SHARP
JACKS
1603-1604 2113-1806-0 1P RCA JACK BK GOLD W/SHIELD
1605 2113-1121-0 2P RCA JACK Y/Y AU HSP-242V-22
CAPACITORS
C763, C764 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C765, C766 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
DIODES
D756-D759 4804-1480-C DIODE 1N4148 ATS
WAFER
J101B 2102-101S-004 WAFER 10P P2.5 ST. (COULOMB)
RESISTORS
R759 4701-102J-C RCF 1/8W 1K 5% ATS
R760 4701-102J-C RCF 1/8W 1K 5% ATS
R761 4701-101J-C RCF 1/8W 100R 5% ATS
R762 4701-104J-C RCF 1/8W 100K 5% ATS
IC
U761 3130-7370-0 IC 74HCT00 NAND GATE
KEYBOARD ASSEMBLY
PC BOARD
2101 * AH PCB-N0910C-KEY PCB ASSY KEYBOARD N091XC
2101 * C PCB-N0911C-KEY PCB ASSY KEYBOARD N091XC
VFL
2119 2460-1890-1 VFD 12-MT-79GNK FUTABA
CAPACITORS
C201 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
Reference No. Part No. Description
