NAD T 751 - Page 46

56
C202 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5 x2
C203-C204 150F-220K-5-GG CC 50V 22pF 10% RL 4x4
C205 150F-104Z-5-IU CC 50V 0.1µF +80/-20% RL 5x11
C206 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
C207 150F-104Z-5-IU CC 50V 0.1µF +80/-20% RL 5x11
C208 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
DIODES
D201-D202 4804-1480-C DIODE 1N4148 ATS
D203 4837-5V61-2 DZ 1/2W 5.6V ROHM AT
D205 *C 4804-1480-C DIODE 1N4148 ATS
D206-D207, D209 4804-1480-C DIODE 1N4148 ATS
CONNECTORS
J201A 7703-1360-2004 CONN.ASSY 3P P205 L=360 AWG26
J202A 7704-1200-2004 CN ASSY 4P P=2.5 L=200
J203A 2101-1581-0 FLEXIBLE CONN. 35P P1.25 SIDE ENTRY
J204A 7706-1100-2004 CONN ASSY AWG26 6P P2.5 L=100
J206A 2101-1581-0 FLEXIBLE CONN. 35P P1.25 SIDE ENTRY
J207A 7703-1090-2004 CONN. ASSY 3P P2.5 L=90
WAFER
J208C 2102-8002-3-100 WAFER 2 PIN 9mm
COIL
L201 1801-220K-M COIL 22µH 10% AL BL7
SWITCHES
M201-M217 5200-3538-0 SWITCH, TACT SKHHBY 7mm HIGH
SENSOR
M218 4814-3TE2-3 IR SENSOR PIC-12043TE2
CRYSTAL
M219 2300-3150-0 CRYSTAL 10MHZ +/-30PPM LOAD CAP 22P
HC49U
TRANSISTORS
Q201 4860-0050-5 TR SS8050 C/D SAMSUNG RL
Q202 485C-144E-5 TR DTC144ES ROHM
Q204 485A-114E-5 TR DTA114ESA ROHM
RESISTORS
R201-R203 4701-681J-C RCF 1/8W 680R 5% ATS
R204-R206 4701-821J-C RCF 1/8W 820R 5% ATS
R207-R209 4701-182J-C RCF 1/8W 1.8K 5% ATS
R210-R212 4701-222J-C RCF 1/8W 2.2K 5% ATS
R213-R214 4701-472J-C RCF 1/8W 4.7K 5% ATS
R215-R218 4701-103J-C RCF 1/8W 10K 5% ATS
R219 4701-472J-C RCF 1/8W 4.7K 5% ATS
R220-R221 4701-471J-C RCF 1/8W 470R 5% ATS
R222 4701-473J-C RCF 1/8W 47K 5% ATS
R223 4701-474J-C RCF 1/8W 470K 5% ATS
R224 4701-102J-C RCF 1/8W 1K 5% ATS
R225-R226 4701-103J-C RCF 1/8W 10K 5% ATS
R228-R231 4701-223J-C RCF 1/8W 22K 5% ATS
R232-R246 4701-103J-C RCF 1/8W 10K 5% ATS
R247-R250 4701-473J-C RCF 1/8W 47K 5% ATS
R251-R261 4701-103J-C RCF 1/8W 10K 5% ATS
Reference No. Part No. Description
