NAD T 751 - Page 47

57
R262 4701-223J-C RCF 1/8W 22K 5% ATS
R263-R274 4701-104J-C RCF 1/8W 100K 5% ATS
R280 4701-102J-C RCF 1/8W 1K 5% ATS
R282 4701-103J-C RCF 1/8W 10K 5% ATS
ICs
U201 3131-3810-1 IC LC87F65C8A 8 BIT MCU MASKED
U202 3131-3920-0 IC EEPROM 24C02 2KBIT 8PIN DIP
LED BOARD
ASSEMBLY
PC BOARD
2201 PCB-N0910C-LED PCB ASSY LED N091XC
LED
2202 3700-2489-G LED 3mm GREEN SP
CONNECTOR
J208A 7702-1060-2004 CONN.ASSY 2P P2.5 L60 AWG26
LOAD BOARD ASSEMBL
Y
PC BOARD
2601 PCB-N0910C-LOAD PCB ASSY LOAD N091XC
CAPACITORS
C703-C704 157F-106M-5-IU CE 50V 10µF 20% RL 5x11
C705 150F-104Z-5-IU CC 50V 0.1µF +80/-20% RL 5x11
C706-C707 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
DIODES
D701 4840-7060-0 DIODE BRIDGE RS804M
D703 4804-1480-C DIODE 1N4148 ATS
WAFERS
J204B 2102-061R-004 WAFER 6 PIN P2.5
J504B, J702B 2102-061S-004 6P ST. WAFER P=2.5 COULOMB
TRANSISTORS
M701-M702 4860-5270-5 TR TYN412 400V 12A THYRISTOR
Q701 4860-0660-5 TR 2SA1015 (G.R.) RL
Q702 4860-0700-5 TR 2SC1815 (G.R) RL
Q703 4860-0660-5 TR 2SA1015 (G.R.) RL
Q704 4860-0700-5 TR 2SC1815 (G.R) RL
RESISTORS
R701 4701-102J-C RCF 1/8W 1K 5% ATS
R702 4701-223J-C RCF 1/8W 22K 5% ATS
R703 4701-101J-C RCF 1/8W 100R 5% ATS
R704-R705 4701-102J-C RCF 1/8W 1K 5% ATS
R706 4701-103J-C RCF 1/8W 10K 5% ATS
R707 4701-101J-C RCF 1/8W 100R 5% ATS
R708 4701-223J-C RCF 1/8W 22K 5% ATS
R709 4701-103J-C RCF 1/8W 10K 5% ATS
R710 4701-472J-C RCF 1/8W 4.7K 5% ATS
R711 4701-102J-C RCF 1/8W 1K 5% ATS
R716-R717 4701-104J-C RCF 1/8W 100K 5% ATS
R718-R719 4701-222J-C RCF 1/8W 2.2K 5% ATS
R720 4701-684J-C RCF 1/8W 680K 5% ATS
Reference No. Part No.
Description
