NAD T 751 - Page 48

58
IC
U701 3130-0890-0 IC NJM4558D DUAL OP AMP.
MAIN BOARD
ASSEMBLY
PC BOARD
2301 PCB-N0910C-MAIN PCB ASSY MAIN N091XC
CAPACITORS
C717 157E-338M-5-5$ CE 25V 3300µF 20% RL 16x32
C718 157E-108M-5-X& CE 25V 1000µF 20% RL 12.5x25
C720, C721 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
C722-C723 157F-106M-5-GM CE 50V 10µF 20% RL 4x7
C726 157F-476M-5-LU CE 50V 47µF 20% RL 6.5x11
C727 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
C728 157F-107M-5-OW CE 50V 100µF 20% RL 8x12
C731 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
C732 157F-106M-5-GM CE 50V 10µF 20% RL 4x7
C734 157F-476M-5-LU CE 50V 47µF 20% RL 6.5x11
C735 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C736 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
C741-C744 157C-337M-5-OVK CE 10V 330µF 20% RL 8x11.5 ELNA
C930 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
DIODES
D715-D718 4805-3930-2 DIODE 1N5393 200V 1.5A AT
D720-D721 4804-0040-1 DIODE 1N4004 AL
D722 4837-27V0-2 DZ 1/2W 27V(26.2-27.6)AT
D731-D734 4804-1480-C DIODE 1N4148 ATS
J7159-J160 4804-0010-2 DIODE 1N4001 AT
WAFERS
J206B 2101-1591-0 FLEXIBLE CONN. 35P P1.25 TOP ENTRY
J401B 2102-111S-004 11P ST.WAFER P=2.5 COULOMB
J502B 2102-121S-004 12P ST.WAFER P=2.5 COULOMB
J7001, J701B 2102-031S-004 3 PIN ST. WAFER P=2.5 COULOMB
J703A 2101-1621-0 WAFER (PCB/PCB) 10P P2.0 ST
J704A 2101-1641-0 WAFER (PCB/PCB) 16P P2.0 ST
J705A-J711A 2101-1621-0 WAFER (PCB/PCB) 10P P2.0 ST
TRANSISTOR
Q724 4860-0660-5 TR 2SA1015 (G.R.) RL
RESISTORS
R731 4701-102J-C RCF 1/8W 1K 5% ATS
R732 4701-333J-C RCF 1/8W 33K 5% ATS
R733-R734 4718-391J-2-X RMF 1W 390R 5% AT
R741-R744 4701-472J-C RCF 1/8W 4.7K 5% ATS
ICs
U721 3130-2520-3 IC 7812 12V REGULATOR
U722 3130-3800-0 IC UPC79M12HF REGULATOR
U723 3130-8190-0 IC NJM78M56FA 5.6V REGULATOR
U724 3130-2020-2 IC 7805 REG 5V
MUL
TI-CHANNEL BOARD
ASSEMBLY
PC BOARD
1101 PCB-N0910C-MUTI PCB ASSY MULTI CHI N091XC
Reference No. Part No. Description
