68
U903 3131-3760-0 IC LC7218 PLL FREQ SYNTHESIZER SANYO
VIDEO BOARD
ASSEMBLY
PC BOARD
1301 PCB-N0910C-VD PCB ASSY VIDEO N091XC
JACKS
1302 2113-1810-0 1P RCA JACK YL GOLD W/SHIELD
1303 2113-1811-0 4P RCA JACK YL GOLD W/SHIELD
1304 2113-1812-0 2P RCA JACK YL GOLD W/SHIELD
CAPACITORS
C441 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C450 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
C459-C461 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C464 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C466-C467 157C-477M-5-OU CE 10V 470µF 20% RL 8x11
C468 157D-108M-5-S9 CE 16V 1000µF 20% RL 10x20
C470 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C476 157C-477M-5-OU CE 10V 470µF 20% RL 8x11
DIODES
D414-D415 4804-1480-C DIODE 1N4148 ATS
SOCKET
J708B 2101-1801-0 SOCKET (PCB/PCB) 10P P2.0
TRANSISTORS
Q428, Q434-Q435 485A-933S-5 TR 2SA933S HFE 120-560 ROHM
RESISTORS
R439 4701-471J-C RCF 1/8W 470R 5% ATS
R460-R461 4701-121J-C RCF 1/8W 120R 5% ATS
R464-R466 4701-680J-C RCF 1/8W 68R 5% ATS
R483, R491-R493 4701-820J-C RCF 1/8W 82R 5% ATS
IC
U404 3131-3730-0 IC BA7625 2X5CH MULTIPLEXER ROHM
VIDEO-5 BOARD
ASSEMBLY
PC BOARD
1901 PCB-N0910C-VD5 PCB ASSY VIDEO-5 N091XC
JACKS
1902 2113-1290-0 1P RCA YL GOLD PLATED GND
1903 2113-1291-0 1P RCA WH GOLD PLATED GND
1904 2113-1292-0 1P RCA RD GOLD PLATED GND
1905 2113-1011-0 PHONE JACK 6312-03-070 W/CLIP
CAPACITORS
C4101-C4102 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C4103 157F-225K-5-GM CE 50V 2.2µF 10% RL 4x7
C4104 150F-223Z-5-UG CC 50V 0.022µF +80/-20% RL 11x4
C4105-C4106 150F-102K-5-IF CC 50V 1000pF 10% RL 5x3.5
C4107 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
CONNECTOR
J401A 7711-1320-2004 CONN.ASSY 11P P2.5 L=320 AWG 26
Reference No. Part No. Description
