NAD T 751 - Page 59

69
RESISTORS
R4101-R4102 4701-331J-C RCF 1/8W 330R 5% ATS
R4103 4701-820J-C RCF 1/8W 82R 5% ATS
VOLUME BOARD
ASSEMBLY
PC BOARD
2001 PCB-N0910C-VOL PCB ASSY VOLUME N091XC
WAFER
J207B 2102-031S-004 3 PIN ST. WAFER P=2.5 COULOMB
ROTARY
M301 4750-6000-0 ROTARY ENCODER EC16B2425 ALPS
TRIGGER BOARD ASSEMBLY
PC BOARD
2002 PCB-N0970C-PHON PCB ASSY TRIGGER BOARD N0970C
CAPACITORS
C001 157F-476M-5-LU CE 50V 47µF 20% RL 6.5x11
C002 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C003 150F-223K-2-FD CC 50V 0.022µF 10% AT 3.2x2.2
WAFERS
M001 2102-021S-005 WAFER 2P ST. P=2.5 COULS
M001C 7702-1250-2005 CN. ASSY 2P P2.5 L=250
JACK
M002 2113-1179-0 PHONE JACK D3.5 BK JY-3537-01-140
RESISTORS
R001 4701-472J-C RCF 1/8W 4.7K 5% ATS
R002 4707-100J-2 RCF 1/2W 10R 5% AT
IC
U001 3130-2520-3 IC 7812 12V REGULATOR
Reference No. Part No. Description
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film, RWR-Wirewound Metal Oxide Film, RMG-1/10W
SMD 0805, RCFA-Thick Film Resistor Network.
