ZONE CONTROLS
Depending on the settings made at the separate ‘Zone Setup’ menu under the ‘Setup Menu’ section
discussion, the applicable Zone can be congured and managed via this ‘Zone Controls’ window.
Select ‘On’ to activate the applicable Zone. When activated, the Source input for the particular Zone
can be allocated by selecting through the following inputs – All enabled Sources, Front Input, Media
Player, Tuner and Local.
Select ‘LOCAL’ as your selected Zone’s Source input if you wish to enjoy the same source as the main
Zone and allow simultaneous listening, but with full separate volume levels.
If a Zone is set to ‘O,’ it is deactivated or powered o.
‘Volume’ refers to the adjustable secondary Zone Volume level that can be increased or decreased
using the buttons of the HTR 3 or front panel’s.
When a Zone is activated, a corresponding Zone number is illuminated at the VFD. Zone 2 is always
available to be congured at ‘Zone Controls’ menu. For Zone 3 and Zone 4 to become available at the
‘Zone Controls’ window, their corresponding ‘Mode’ in the ‘Zone Setup’ menu under the ‘Setup Menu’
section should be set to ‘Zone (Audio Only).’
NOTE
The ZR 4 remote control will only control Zone 2 applications. Zone 3 and Zone 4 could be
congured and managed at the appropriate Zone OSD menu using the front panel navigations
buttons as well as the corresponding keys on the HTR 3 remote control.
OPERATION
USING THE T 775  MAIN MENU
16
