Nagra PL-P - Tube, Jumpers and Timer Positions

12
Tube, Jumpers and Timer Positions
Line stage tube timer Phono stage tube timer 12AX7(ECC83) Phono input stage
Jumpers 12AX7 (ECC83) Line output stage
12AT7 (ECC81) Line output stage
Phono transformers 12AX7 (ECC83) Line input stage Headphone transformers
12AT7 (ECC81) Phono output stage 12AT7 (ECC81) Line input stage
