Electrical
Phono stage
Moving coil Sensitivity 0.1 mV
Loading 0.1 ~ 47kΩ
S/N ratio 74 dB 0.5 mV, A-weighted
Moving magnet Sensitivity 0.5 mV
Loading 47 ~ 837pF
S/N ratio 80 dB 5.0 mV, A-weighted
Measurement conditions:
Input potentiometers at maximum position, Output potentiometer at 0 dB position.
Line stage
Input impedance >100 kΩ
Output impedance 60 Ω
S/N ratio > 88 dB A-weighted
Bandwith 22 ~ 60kHz +0/-1 dB
Distorsion < 0.02 % 1 V out, no load at 1 kHz
< 0.1 % 1 V out, 600Ω load
< 0.1 % 1 V out, 3kΩ.load
Measurement conditions :
All potentiometers at 0 dB position
Physical
Tubes Phono stage 1 12 AT 7 / ECC 81
1 12 AX 7 / ECC 83
1 5,000-hour usage timer
Line stage 2 12 AT 7 / ECC 81
4 12 AX 7 / ECC 83
1 compteur 5,000 heures
Source d’alimentation
« D » size Nickel-Cadmium
rechargable power cells 4 Ah
Recharged via PLP-CCC3 AC power
supply unit
Dimensions
Width 12.2” 310 mm
Depth 10.0” 254 mm
Height 3.0” 76 mm
Weight
9 lbs 13 oz. 4.45 kg with 8 « D » cells
