NAIM NAP V175 - NAP 300 Connection & Specifications; NAP 300 connection to NA PS300 Power Supply; Specifications

NA PS300 rear
mains in
7
NAP 300 Connection & Specifications
9.1 NAP 300 connection to NA PS300 Power Supply
left
speaker ch1
-+
right
speaker ch2
to preamp
power
supply.
right, ch2
-+
to preamp
power
supply.
left, ch1
1 2
Input Socket 1 Input Socket 2
ch1
-ve
-ve
nc
nc
ch 2
9.2 Specifications
NAP 300 & NA PS300
Power Output
Continuous, 8 ohms 90 Watts per channel
Transient 500VA
Quiescent Power Consumption 27VA
Voltage Gain +29dB
Input Impedance 18 kilohms
Frequency response -3dB @ 2Hz and 70kHz
Mains Supply: 100V. 115V. 230V - 50/60Hz
Case size (H x W x D)
NAP 300 87 x 432 x 314mm
NA PS300 87 x 432 x 314mm
Weight
NAP 300 10.7kg
NA PS300 14.1kg
