NANO NDL-080 - Product Overview

8
heatless desiccant air dryer
D2
number description
1 compressed air inlet
2 air outlet
3 column
4 exhaust silencer
5 exhaust valve ‘A’
6 inlet valve ‘A’
7 inlet valve ‘B’
2.3 product overview
number description
8 exhaust valve ‘B’
9 shroud
10 control panel display
11 top cover
12 shroud latches
13 Gauge ‘A’
14 Gauge ‘B’
