GEM-P1632 Installation Instructions
WI808F 8/03
!
Page 49
Keypad Programming Modes: Keypad Configuration Mode
KEYPAD CONFIGURATION MODE
GEM-RP1CA/1CAe/1CAe2/
GEM-K1CA KEYPADS
Press
R
(or
A
) button
Enter Factory Code:
11123
Configure:
•
Keypad Beep ON/OFF
• Entry Sounder
•
Keypad Address 01
• New Compat# 000 **
Press
C
button
(“
01 OUT OF SYSTEM
”)
Return Jumper JP1 * from Pins 2-3 to Pins 1-2
(“
SYSTEM READY
”)
Move Jumper JP1 * from Pins 1-2 to Pins 2-3
(Wait about 15 seconds: “
OUT OF SYSTEM
”)
Configure:
•
Keypad Address (Jumpers J1-J3)
• Touchpad Backlight (Jumper A)
•
LCD Backlight (Jumper B)
GEM-RP2AS/RP2ASe/RP2ASe2
KEYPADS
* JP1 is located at the top center of the circuit board.
** Not available in the GEM-P1632.
12
4
3
56
7890
A
B
C
D
E
F
G
NEXT/YES
PRIOR/NO
AREA
Scroll Down
Scroll Up
Exit
Yes
No
For "Classic" Keypads
12
4
3
56
7890
A
B
C
D
E
F
G
NEXT/YES
PRIOR/NO
AREA
Scroll Down
Scroll Up
Exit
Yes
No
R
For "K Series" Keypads
