GEM-P1632 Installation Instructions
L
NAPCO Security Systems
WI808F 8/03
!
Page 50
GEM-P1632 Wiring Diagram
GEM-P1632 WIRING DIAGRAM
NORMAL
KEYPAD
CONFIGURE
JP3
(GEM-RP1CAe2) 2 LINE KEYPAD
NOTES: 1. ALARM CURRENT CAN BE INCREASED BY REDUCING STANDBY CURRENT BY THE SAME AMOUNT.
2. THE FOLLOWING DEVICES MAY BE PLACE ON THE REMOTE BUS: GEM-RP1CAE2, GEM-RP2ASE2, GEM-EZM816, GEM-X10, GEM-RECV8,
GEM-RECV16, GEM-RECV96, RM3008, GEM-EVA1, WIZARD2, GEM-K1CA, GEM-K2AS AND GEM-K3DGTL.
3. REFER TO WI808 FOR U.L. LISTINGS
4. COMBINED STANDBY CURRENT = KEYPAD CURRENT + AUX CURRENT + FIRE POWER + PGM1 AND PGM2 CURRENT.
5. UNIT INTENDED TO BE MOUNTED VERTICAL ON WALL.
6. REFER TO WI808 FOR COMPATIBLE TWO WIRE SMOKE DETECTORS. DO NOT MIX DIFFERENT MODELS.
7. RECOMMENDED BATTERIES YUASA NP4-12 OR NP7-12. BATTERY SHOULD BE REPLACED EVERY 5 YEARS.
8. THIS PANEL SHALL BE CHECKED BY A QUALIFIED TECHNICIAN AT LEAST ONCE EVERY 3 YEARS.
9. AUX POWER AND FIRE POWER VOLTAGE RATING: 12.5 VDC TO 11.7 VDC. THE PANEL WILL DISREGARD INPUTS FROM ALL SENSORS WHEN
VOLTAGE DROPS BELOW 8.5V.
10. A.C. MUST BE DISCONNECTED WHEN PERFORMING WEEKLY TESTS.
11. THIS PANEL ONLY SUPPORTS ONE SMOKE DETECTOR IN ALARM FOR EACH ZONE.
12. DISABLE AUTO-RESET ON NON-FIRE ZONES FOR SIA CP-01 INSTALLATIONS.
(-)
E15
LA1469C
(E)
(E)
(E)
(E)
6
(NOTE 7)
ACTIVE WHEN
REPORTING
AR MED
STATUS
TIP TIP RING RING
DESIGN EVALUATED BY UL IN
ACCORDANCE WITH
SIA CP-01
CONTROL PANEL STANDARD
FEATURES FOR FALSE
ALARM REDUCTION
JP1
