GEM-P1632 Installation Instructions
L
NAPCO Security Systems
WI808F 8/03
!
Page 4
INTRODUCTION
GENERAL DESCRIPTION
Napco's Gemini GEM-P1632 is a state-of-the-art microcomputer-based burglary and residential fire alarm control panel
of modular design. Integrally an 8-zone panel, it will support up to 32 zones with the use of zone doubling, optional zone
expansion modules, wireless receiver modules and/or GEM-RP1CAe2/GEM-K1CA Keypads. Each panel includes an
integral digital communicator.
The control panel features programmable area partitioning. That is, the system may be divided into up to two discrete
multiple-zone areas, each allowing access by only those users programmed for their respective area.
Opening Suppression and Closing Suppression, available through Napco Quickloader software, suppress reporting
within programmed “windows”. Conversely, Exception Reporting can transmit a “fail to close” if the panel is not armed
within programmed intervals and, similarly, a “fail to open” if the panel is not disarmed within programmed intervals.
Furthermore, the panel can be programmed to automatically arm either area at any time. A log containing up to 400
events (accessible through Quickloader
TM
software) monitors control-panel activity referenced to a precision real-time
clock. A detailed event history may be displayed at the computer, using Napco’s PCD-Windows Quickloader Software.
Keypads feature a liquid-crystal display for messages. In normal use, the LCD shows zone identification and status
messages. Conventional LEDs and a sounder are also provided for annunciation.
Data may be quickly and easily downloaded to the control panel using a PC-compatible computer with Napco's PCD-
Windows Quickloader software and PCI2000 computer interface. Or, the panel may be programmed using the keypad in
its secondary mode of operation. In the keypad programming modes (there are two: Dealer and User), the LCD shows
memory address, data values, programming prompts, and the alphanumeric characters required for entering up to 32
user codes and custom zone descriptions.
FEATURES
Control Panel Features
!Eight end-of-line-resistor burglary zones programmable for Area (expandable to sixteen end-of-line resistors with
zone doubling), Exit/Entry Delay, Interior (Stay) Bypass, Exit/Entry Follower, Day Zone, Chime, Fire options,
Swinger Shutdown, Zone Anding and a variety of other features.
!
Supports up to 32 zones with optional zone-expansion modules, wireless receiver modules and 4-zone keypads.
!
Supports up to 32 individually coded users.
!
Supports three outputs (Bell, PGM1 and PGM2) and up to 8 external relay outputs (using Relay Module RB3008,
RM3008 or the GEM-OUT8. See
Relay Control
in glossary for more information).
!
Supports three keypad panics: Fire, Police & Auxiliary
!
Supports two independent area partitions.
!
Supports up to seven separate access stations (keypads) by up to 32 users.
!
Supports up to 8 separately-addressable X-10 devices with the GEM-X10 KIT and PC04 interfaces.
!
English-language prompts & system status messages.
!
User-customized zone descriptions, re-programmable as required.
!
Supports 2-wire and 4-wire smoke detectors.
!
Reports alarms, restores and troubles by zone.
!
400 Event Log.
!
Two programmable entry delay times.
!
One Interior Zone Group
!
Dynamic battery test interrupts charging and places battery under load every four hours.
!
Chime by zone; programmable duration.
!
Quickloader programmable.
!
2 PGM outputs.
!
Supports Gemini Wireless Devices
NOTE:
Failure to install and program as described in this manual for UL-listed systems voids the listing mark of
Underwriters Laboratories, Inc.
