NAPCO Gemini GEM-P3200 User Manual

L NAPCO Security Systems
X GEM-P3200 Programming Instructions

Page 41
WI1184B 2/06
ZONE OPTIONS / ZONES 17-32 (ADDRESS 1402-1586)
ZONE OPTIONS / ZONES 17-32
See Zone Options on Page 43.
ZONE OPTIONS ZONES 29-32
LEFT DATA VALUES
(CIRCLE
)
ADDRESS
1502-1586
ZONES 25-28
RIGHT DATA VALUES
(CIRCLE
)
ZONES 21-24
LEFT DATA VALUES
(CIRCLE
)
ADDRESS
1402-1486
ZONES 17-20
RIGHT DATA VALUES
(CIRCLE
)
ZN32 ZN31 ZN30 ZN29 L ADDR R ZN28 ZN27 ZN26 ZN25 ZN24 ZN23 ZN22 ZN21 L ADDR R ZN20 ZN19 ZN18 ZN17

Priority 8 4 2 1 1502 8 4 2 1 8 4 2 1 1402 8 4 2 1
Priority with Bypass 8 4 2 1 1503 8 4 2 1 8 4 2 1 1403 8 4 2 1
Auto-Bypass 8 4 2 1 1504 8 4 2 1 8 4 2 1 1404 8 4 2 1

Selective Bypass 8 4 2 1 1505 8 4 2 1 8 4 2 1 1405 8 4 2 1
Keyswitch Arming 8 4 2 1 1506 8 4 2 1 8 4 2 1 1406 8 4 2 1
Auto-Bypass Re-entry 8 4 2 1 1507 8 4 2 1 8 4 2 1 1407 8 4 2 1
Pre-Alarm Warning 8 4 2 1 1508 8 4 2 1 8 4 2 1 1408 8 4 2 1
Never Arm 8 4 2 1 1509 8 4 2 1 8 4 2 1 1409 8 4 2 1
24-Hour Zone 8 4 2 1 1510 8 4 2 1 8 4 2 1 1410 8 4 2 1

Burg. Alarm Output 8 4 2 1 1511 8 4 2 1 8 4 2 1 1411 8 4 2 1

Pulsed Alarm Output 8 4 2 1 1512 8 4 2 1 8 4 2 1 1412 8 4 2 1
Fire Output (Lug E9) 8 4 2 1 1513 8 4 2 1 8 4 2 1 1413 8 4 2 1
Reset Relay 8 4 2 1 1514 8 4 2 1 8 4 2 1 1414 8 4 2 1
Auxiliary Relay 8 4 2 1 1515 8 4 2 1 8 4 2 1 1415 8 4 2 1
Entry/Exit 1 8 4 2 1 1516 8 4 2 1 8 4 2 1 1416 8 4 2 1
Entry/Exit 2 8 4 2 1 1517 8 4 2 1 8 4 2 1 1417 8 4 2 1
Exit/Entry Follower 8 4 2 1 1518 8 4 2 1 8 4 2 1 1418 8 4 2 1

Auto Reset 8 4 2 1 1519 8 4 2 1 8 4 2 1 1419 8 4 2 1

Swinger Shutdown 8 4 2 1 1520 8 4 2 1 8 4 2 1 1420 8 4 2 1
Chime 8 4 2 1 1521 8 4 2 1 8 4 2 1 1421 8 4 2 1
Abort Delay 8 4 2 1 1522 8 4 2 1 8 4 2 1 1422 8 4 2 1
Power-up Delay 8 4 2 1 1523 8 4 2 1 8 4 2 1 1423 8 4 2 1
Day Zone Open 8 4 2 1 1524 8 4 2 1 8 4 2 1 1424 8 4 2 1
Day Zone Short 8 4 2 1 1525 8 4 2 1 8 4 2 1 1425 8 4 2 1
Alarm on Day Zone 8 4 2 1 1526 8 4 2 1 8 4 2 1 1426 8 4 2 1
RPT Alarm Tel 1 8 4 2 1 1527 8 4 2 1 8 4 2 1 1427 8 4 2 1
RPT Alarm Restore Tel 1 8 4 2 1 1528 8 4 2 1 8 4 2 1 1428 8 4 2 1
RPT Trouble Tel 1 8 4 2 1 1529 8 4 2 1 8 4 2 1 1429 8 4 2 1
RPT Trouble Restore Tel 1 8 4 2 1 1530 8 4 2 1 8 4 2 1 1430 8 4 2 1
RPT Alarm Tel 3 8 4 2 1 1535 8 4 2 1 8 4 2 1 1435 8 4 2 1
RPT Alarm Restore Tel 3 8 4 2 1 1536 8 4 2 1 8 4 2 1 1436 8 4 2 1
RPT Trouble Tel 3 8 4 2 1 1537 8 4 2 1 8 4 2 1 1437 8 4 2 1
RPT Trouble Restore Tel3 8 4 2 1 1538 8 4 2 1 8 4 2 1 1438 8 4 2 1
No EOL Resistor 8 4 2 1 1539 8 4 2 1 8 4 2 1 1439 8 4 2 1
Sensor Watch 8 4 2 1 1540 8 4 2 1 8 4 2 1 1440 8 4 2 1
Trouble on Open 8 4 2 1 1541 8 4 2 1 8 4 2 1 1441 8 4 2 1
Trouble on Short 8 4 2 1 1542 8 4 2 1 8 4 2 1 1442 8 4 2 1
Trouble on Night Open 8 4 2 1 1543 8 4 2 1 8 4 2 1 1443 8 4 2 1
Zone Area 1 8 4 2 1 1544 8 4 2 1 8 4 2 1 1444 8 4 2 1
Zone Area 2 8 4 2 1 1545 8 4 2 1 8 4 2 1 1445 8 4 2 1
RESERVED 8 4 2 1 1553 8 4 2 1 8 4 2 1 1453 8 4 2 1
Zone ANDing Group 1 8 4 2 1 1554 8 4 2 1 8 4 2 1 1454 8 4 2 1
Zone ANDing Group 2 8 4 2 1 1555 8 4 2 1 8 4 2 1 1455 8 4 2 1
Interior #1 Bypass 8 4 2 1 1562 8 4 2 1 8 4 2 1 1462 8 4 2 1

Interior #2 Bypass 8 4 2 1 1563 8 4 2 1 8 4 2 1 1463 8 4 2 1
Keypad Sounder on Alarm 8 4 2 1 1564 8 4 2 1 8 4 2 1 1464 8 4 2 1
Fire (C) 8 4 2 1 1575 8 4 2 1 8 4 2 1 1475 8 4 2 1
Fire Alarm Verification (C) 8 4 2 1 1576 8 4 2 1 8 4 2 1 1476 8 4 2 1
Interior (STAY) Bypass 8 4 2 1 1584 8 4 2 1 8 4 2 1 1484 8 4 2 1
Chime 2 8 4 2 1 1586 8 4 2 1 8 4 2 1 1486 8 4 2 1
 When the Easy Program Menu is used, these features are enabled by default (for new panels or after a Cold Start (address 4093)).
 Do not program if "K Series" keypads (with "
P" and "Q" buttons) are used in the system.
 Disable Auto-Reset on non-fire zones for SIA CP-01 installations.
 In UL installations, all Fire Zones must also be programmed for "PulseBurg Output Cadence" (Address 2422, press 1 (bit zero)).
1 4 4 4 4 2 2 2 2
