L NAPCO Security Systems
X GEM-P3200 Programming Instructions
Page 5
WI1184B 2/06
EASY MENU DRIVEN PROGRAM MODE
DEALER PROGRAM - PRELIMINARY INFORMATION
Only Keypad #1 may be used for both Dealer and User programming, however this keypad may be located in any area.
The Master Security Code is printed on the panel’s microprocessor can. Use this code to enter the Dealer Program Mode to program a
custom Dealer Security Code. Record the number, then remove the code label to prevent unauthorized access to the panel. If you
forget your Dealer Security Code, use the Master Security Code to enter programming.
After entering codes or data, press the save U button. Data will not be stored into memory unless U is pressed.
If the keypad is in the Program Mode and no activity is detected for longer than 4 minutes, a steady tone will sound.
Silence the sounder by the G button to continue, or by pressing the C button to exit.
A panel that has been COLD STARTED (Address Location 4093) performs identically to a new panel.
When programming a Multiple Area System, Direct Address Programming Mode must be used to complete the program.
KEYPAD #1: For ease of programming, it is recommended that a GEM-RP1CAe2 or GEM-K1CA be used as Keypad #1.
(Regardless of which keypad is selected, all new keypads are configured as Keypad #1 out of the box). If a GEM-RP2ASe2/
GEM-K2AS is used, configure address jumpers as Keypad #1 (see Configuring the GEM-RP2ASe2 Keypad, page 65).
1. Press EEEEEE R
2. Press "PRIOR/NO" button until “TURNON PROG Y/N” (GEM-RP2ASe2/
GEM-K2AS) or “17” (GEM-RP3DGTL/GEM-K3DGTL or
GEM-RP4RFC/GEM-K4RF) appears on the LCD screen.
3. Press "NEXT/YES" button to Enter Dealer Program Mode.
4. Press CC to exit Dealer Program Mode when finished.
• Number of Zones in Area 1
• Number of Zones in Area 2
• Fire Zones in Area 1
• 2-Wire Fire Zones in Area 1
• Report All Zones to Central
• Exit/Entry Zones in Area 1
• Interior Zones in Area 1
• 24 Hour Zones in Area 1
• Chime Zones in Area 1
• Chime 2 Zones in Area 1
• Exit/Entry2 Zones in Area 1
• 50mS Loop Response Zones (Note: 750mS is
required for Loop Response time in UL installations).
• Aux Output Activated on Alarm Zones
• Sensor Watch Zones
• Keypad Sounder on Alarm Zones
• Auto Bypass re-entry Zones
• Enable no EOLR Zones
• Number of Keypads in Area 1 and 2
• Central Station Receiver 1 Tel. Number
• Central Station Receiver 1 Account Number
• Central Station Receiver 1 Format
• Enter User Codes
• RF Transmitter Points
• Quick Method (Enroll Method)
• Keyfob Transmitters
• Enter Zone Descriptions
• Dealer Code
• Enable Telco Line Fault Test
• Enable Burg Output Chirp on Keyfob
• Enable CP-01
NEW PANELS: The custom default program may be created for new panels only. Once the panel has been programmed by any
means, the number zones will be suppressed and cannot be changed. Should it be necessary to create a new custom default
program, (a) from the Dealer Program Mode, press the
C button to enter the Direct Address Program Mode; (b) access Location
4091 (Clear Program); (c) press the
U button and start over.
EASY MENU DRIVEN PROGRAM MODE
ACCESSING DEALER PROGRAM MODE
CUSTOMIZING A DEFAULT PROGRAM
For new panels, you can design a default program that will best suit your application. Using this procedure, you will configure the panel for:
This procedure will automatically set up system keypads, EZMs, wireless transmitters, etc. After your basic default program has
been loaded, you may alter it as necessary in the Direct Address Program Mode.
Master Security Code
(on microshield)
R
GEM-P3200
CONTROL
COMMUNCIATOR
MASTER SECURITY CODE
# - # - # - # - # - #
To Next Page
