NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 1
Page 14 Programming Instructions, Volume 1
cuits are disabled; steady when silenced or
acknowledged.
 SILENCED Icon - On steady when Fire alarm is
silenced.
 FIRE LED - Flashes when in Fire alarm; steady
when silenced.
 AC ON LED - On when AC power is present; off
when AC power is absent.
FUNCTIONS OF BUTTONS
 Numbers 0-9 - Used to enter User Codes to
"unlock" the system; view status, access functions
or select zone/output.
 MENU - Press to display / scroll through menu
options (when system is unlocked).
 SILENCE (DISABLE) - Silences alarm sounders
(when system is unlocked). In the ZONE DIREC-
TORY, ZONE DISABLE, OUTPUT DIRECTORY or
OUTPUT BYPASSED MENU displays; this button
toggles the displaying zone/output between disa-
bled and un-disabled.
 RESET - Acknowledges condition (s) have been
viewed (flashing icons changed to steady), thus
allowing new conditions to display clearly with
flashing icons. Initiates reset sequence, allowing
alarms, supervisory conditions and troubles to re-
store.
 ENTER (UNLOCK) - Press to enter User Code or
activate displayed menu option.
 NEXT - Activates the displayed menu option
(when system is unlocked) or prompts the next
zone/output to display.
 PRIOR – Prompts for the previous zone/output to
display (when system is unlocked).
 ACK. - Acknowledges condition (s) have been
viewed (flashing icons changed to steady), thus
allowing new conditions to display clearly with
flashing icons.
ADVANCED MENU FUNCTIONS
 LOCK KEYPAD - Immediately locks keypad
against affecting any system operation.
 DISPLAY FIRE LOG - For Fire Chief / serviceman
use. See OI341.
TESTING THE SYSTEM
After installation is completed, always test the system
by first calling the central station to inform them of the
test. Then initiate an alarm, preferably on a zone that
activates a steady output, then silence and reset the
zone after initiating an alarm. Verify proper signaling,
then call the central station to confirm their receipt of a
valid transmission.
FIRE TEST MODE
1. Unlock the keypad using the Dealer Code or Mas-
ter Code. "Keypad Unlocked" flashes momen-
tarily on the keypad LCD.
2. Press NEXT and PRIOR to scroll through options
until "Do One Man Test" displays.
3. Press ENTER. Note that the system is in "Test
Mode" and will not function "normally". A report is
sent to the central station.
4. Activate each initiating device one at a time (for
example, blow smoke into the smoke detectors,
activate each pull-station, etc.). When detected
by the system, all output circuits programmed to
activate when the associated zone is in alarm will
sound a single momentary chirp.
5. Restore the device (blow clean air through the
smoke detectors, restore each pull station, etc.).
When the system detects the zone restored, all
associated zones will sound 2 short chirps.
6. When all Fire devices have been tested and the
mapped outputs confirmed, end the Test Mode by
pressing RESET on the keypad. Note: If in Test
Mode for more than 5 minutes, you must unlock
the keypad before exiting.
BASIC OPERATION (CONT'D)
