NAPCO GEMINI GEMC-128 - CS RECEIVER AND REPORTING OPTIONS; CS Receiver Format and Options

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 1
NAPCO Security Group
Programming Instructions, Volume 1 Page 57
ADDRESS 1038
CS Receiver 1
Format
ADDRESS 1060
CS Receiver 2
Format
Default for CS Receiver 1 Format depends on Easy Menu Question “RCVR FORMAT”. [Default = • (blank) (E)] for CS Receivers 1, 2 and 3 Formats.
CS RECEIVER FORMAT OPTIONS (ADDRESS 1038, 0526, 1060, 0551, 1082 & 0576)
Default for CS Receiver 1 Format depends on Easy Menu Question “RCVR FOR-
MAT”. [Default = •(blank) (E)] for CS Receivers 2 and 3 Formats.
CS RECEIVER FORMATS: Up to 3 CS Formats may be programmed.
1. Select the desired CS Receiver Format from the table shown.
2. Enter the corresponding digit in the address location for each CS Receiver.
NOTE: Dark shaded data value box shows option not available. Press
U to
NOTES:
* If both are selected, 1400Hz has priority over 2300Hz.
** For NAPCO NetLink™ installations only: For each telephone num-
ber desired, enable to allow the panel to report alarms via the NL-MOD
accessory. See WI1242 for more information.
ADDRESS 1082
CS Receiver 3
Format
0526
CS Receiver 1 Options
0551
Default
Option
Default
Option
OFF
1 1400Hz Handshake/Kissoff *
OFF
1 1400Hz Handshake/Kissoff *
OFF
2 2300Hz Handshake/Kissoff *
OFF
2 2300Hz Handshake/Kissoff *
OFF
3 Enable Zone Number on Pulse Alarm
OFF
3 Enable Zone Number on Pulse Alarm
OFF
4 Single Digit Only
OFF
4 Single Digit Only
OFF 5 Sum Check OFF 5 Sum Check
OFF 6 3/1 with Extended Restores OFF 6 3/1 with Extended Restores
OFF 7 Report to TCP/IP Receiver (Telco 1)** OFF 7 Report to TCP/IP Receiver (Telco 2)**
OFF 8 RESERVED OFF 8 RESERVED
CS Receiver 2 Options
0576
Default
Option
OFF
1 1400Hz Handshake/Kissoff *
OFF
2 2300Hz Handshake/Kissoff *
OFF
3 Enable Zone Number on Pulse Alarm
OFF
4 Single Digit Only
OFF 5 Sum Check
OFF 6 3/1 with Extended Restores
OFF 7 Report to TCP/IP Receiver (Telco 3)**
OFF 8 RESERVED
CS Receiver 3 Options
DATA ENTRIES
CS RECEIVER FORMATS
LEFT RIGHT
blank (•) blank (•)
Ademco Point ID***
blank (•)
1
SIA***
blank (•)
2 AES (not used)
blank (•)
3
GEMC-NL-MOD (Sends proprietary
format to NAPCO NetLink NL-CSRCV
Central Station Receiver)
***These formats do not
use programmable
codes, but Event ID
Codes to identify the
type of zone as fol-
lows:
01 – Fire
02 – Panic
03 – Burglary
04 – Holdup
05 – Fire Supervision
06 – Fire Waterflow
08 – Heat Alarm
09 – General Alarm
0A – Auxiliary Alarm
(keypad displays "0")
0B – 24-Hour Auxiliary
Alarm
0C – Burg Perimeter
0D – Burg Interior
0E – Burg Exit/Entry
0F – Tamper
11 – AC Fail
12 – Low Battery (battery
test failure)
13 – Fire Tamper EZM
14 – Ground Fault
15 – Smoke
16 – Combustion
17 – Pull Station
18 – Duct
19 – Carbon Monoxide
