NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 1
Page 26 Programming Instructions, Volume 1
Keypads must be numbered consecutively (missing numbers are not
permitted)
Only Keypad No. 1 may be used for programming
To assign the keypad number, proceed as follows:
1. Enter the assigned keypad number 01–15, then press the
U button to save.
A valid number will be acknowledged by a short beep; an invalid number will
be rejected by a long beep.
2. Press the
R button to continue or press the C button to exit.
EZM Address
The keypad's internal EZM (Expansion Zone Module) may be utilized to provide
four additional wired zones. Whether used alone or in conjunction with optional
GEMC-EZM8 module or other keypad EZM's, it must be assigned a unique ad-
dress (or Group number, see Keypad Programming Workbook) similar to its
keypad address. If no other EZM's are to be used, designate the keypad as
Group "01" at the "EZM ADDRESS 00" display. In multiple-EZM systems, enter
an assigned group number "01" through "22". (Each EZM must have a unique
assigned group number, starting with "01" and proceeding consecutively).
Press the
R button to continue or press the C button to exit.
Zone Response
The normal loop response of each keypad expansion zone is 750mS, however
the response time of any zone can be reduced to 50mS as follows.
1. Of the following, circle the number(s) in parentheses associated with the
zone(s) to be changed: Zone 1=(1); Zone 2=(2); Zone 3=(4); Zone 4=(8)
2. Add up the circled numbers.
3. At the keypad, enter the sum as a two-digit number "01" through "15" on the
display, then press the U button.
Example. Change Zones 2, 3 and 4 to 50mS response.
1. Circle numbers for Zones 2, 3 and 4: (2), (4) and (8).
2. Add up the circled numbers: 2 + 4 + 8 = 14.
3. Enter "14" at the keypad, then press the
U button.
Press the R button to continue or press the C button to exit.
Program Control Message
The Access-Control message normally displays "**ENTER NOW**" however this
display may be changed to any of the following messages as displayed in the
table at right:
Press the
R button to continue (the display will loop back through selec-
tions, for changes) or press the
C button to exit the Keypad Configuration
Mode (display will read "01 OUT OF SYSTEM"). Then replace Jumper JP5
across Pins 1–2 (top two).
0 (No Message)
1 **Enter Now**
2 Door Control
3 Gate Control
4 Light Control
5 Control #1
6 Control #2
Program Control Messages
EZM Address
01
Zone Response
00
Prog Control
Message 1
To Next Page
