NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 1
Page 30 Programming Instructions, Volume 1
Chime Zones in Area 2 and Up (Seen during initial configuration only)
 Enter the zone numbers which are to be used as Chime Zones.
 Valid entries are from 02 to 96. Directly enter each zone number, including leading zeros.
 Press U to save and then repeat for any additional zone(s), press the NEXT button to
proceed.
NOTE: A chime time of 2 seconds will be automatically programmed.
Chime 2 Zones in Area 2 and Up (Seen during initial configuration only)
 Enter the zone numbers which are to be used as Chime 2 Zones.
 Valid entries are from 02 to 96. Directly enter each zone number, including leading zeros.
 Press U to save and then repeat for any additional zone(s), Press the NEXT button to
proceed.
NOTE: A chime time of 2 seconds will be automatically programmed.
Chime 2 zones give a distinct pulsating tone when zone is faulted.
Exit/Entry 2 Zones in Area 2 and Up (Seen during initial configuration only)
 Enter the zone numbers of zones to be used as Exit/Entry zones.
 Valid entries are from 02 to 96. Directly enter each zone number, including leading zeros.
 Press U to save and repeat for any additional zone(s); press the NEXT button to pro-
ceed.
NOTE: An Entry Delay Time of 30 seconds and an Exit Delay Time of 60 seconds will
automatically be programmed.
50mS Loop Response Zones (Seen during initial configuration only)
 Enter the zone numbers of zones to have a 50mS loop response.
 Valid entries are from 01 to 08. Directly enter each zone number, including leading zeros.
 Press U to save and then repeat for any additional zone(s), Press the NEXT button to
proceed. Note: Only panel zones 01-08 can be programmed for Quick Loop Response.
All other zones can be programmed via their respective EZM's (hardwire). Note: 750mS
is required for Loop Response time in UL installations.
Burg Module PGM1 Output Activated on Alarm Zones (Seen during initial configura-
tion only)
 Enter the zone numbers of zones to activate the Burg PGM1 Output upon alarm.
 Valid entries are from 01 to 96. Directly enter each zone number, including leading zeros.
 Press U to save, then repeat for any additional zone(s), Press NEXT to proceed.
NOTE: A
Burg Module PGM1 Output Timeout of 15 minutes will automatically be pro-
grammed.
Sensor Watch Zones (Seen during initial configuration only)
 Enter the zone numbers of zones to be Sensor Watch zones.
 Valid entries are from 01 to 96. Directly enter each zone number, including leading zeros.
 Press U to save and then repeat for any additional zone(s), Press the NEXT button to
proceed.
NOTE: A Sensor Watch Time of 24 hours will automatically be programmed.
Keypad Sounder On Alarm Zones (Seen during initial configuration only)
 Enter the zone numbers of all zones to activate the Keypad Sounder upon alarm.
 Valid entries are from 01 to 96. Directly enter each zone number, including leading zeros.
 Press U to save and then repeat for any additional zone(s), Press the NEXT button to
proceed.
(Direct Entry)
(Direct Entry)
(Direct Entry)
(Direct Entry)
(Direct Entry)
(Direct Entry)
(Direct Entry)
Chime Zones
Enter Zone # 00
Chime 2 Zones
Enter Zone # 00
Exit/Entry 2 Zns
Enter Zone # 00
50mS Loop Zones
Enter Zone # 00
Aux Output Zones
Enter Zone # 00
Sensor Watch Zns
Enter Zone # 00
KP Sndr Alrm Zns
Enter Zone # 00
