SLE-LTE Commercial Series Alarm Communicators -- Installation Instructions 11
Wiring Diagram for BACKUP Reporting Configuration
Generic Control Panels
CONTROL PANEL PC BOARD
GRN RED BRN GRAY
(CONTROL PANEL HOUSING)
GRN RED
YELLOW
BLACK
*For StarLink termi-
nals 1 and 2: May
be wired directly to
Aux Power of the
control panel when
71mA standby
current is available
HOME
PHONES
TO TELCO
RJ31X
RING TIP
(–) (+)
12VDC
AUX POWER
(RING)
(TIP)
(RING)
(TIP)
(TELCO) (PHONE)
YELLOW (–)
BLACK (+)
StarLink
BATTERY
(+)
RED
(–)
BLACK
*Refer to section "SUPPLYING POWER".
6 7 8 15 14 13 12 11 9 10 2* 3 4 5 1*
(–)
PGM1 PGM2 PGM3 IN1 IN2 GND IN3 RING TIP
17 16
RTS
(R)
PANEL
TX (B)
PANEL
RX (G)
CTS
Y
PANEL
RING (+)
PANEL
TIP (–)
(STARLINK RADIO HOUSING)
Power Supply (SLE-ULPS-R)
Either the TRF12/T123
(16.5V / 20VA) transformer
or the chassis-mounted
16.5VAC / 20VA transformer
(optional)
Transformer
TELCO QUAD WIRE
Optional: When Power Supply
SLE-ULPS-R is not used,
connect Panel Aux Power to
StarLink terminals 1 and 2
(observing polarity)
ZONE (+)
DEDICATED
TO
SUPERVISION
8 9 10
N/C
COM
N/O
J2
EOLR
Wire to dedicated
zone on the
control panel for
Supervision when
the Power Supply
board (SLE-
ULPS-R) is not
used.
Note: Battery leads
are not power limited
StarLink Radio Terminals
SLE-LTEV-CB-TF PC Board: All connec-
tions are power limited except AC Mains,
Telco and battery terminals. Terminals 14-
17: No connections permitted.
TELCO
TBL
OUTPUT
Telco TBL
Output
Relay
10K
GND
10K
+V
Note: Connect IN2 to a
panel output used for
identifying Telco line cut
(this is the DACT
interconnect wiring to the
radio).
