Napoleon HD4N - Dimensions; See-Thru (Hd4 St, Hd4 Stg and Hd4 Stc); Peninsula (Hd4 P, Hd4 Pg and Hd4 Pc)

W415-1146 / A / 02.16.13
5
EN
HD4STG ILLUSTRATED
HD4STG ILLUSTRATED
42 3/8”
(1076.3mm)
32 1/4”
(819.2mm)
38 1/4”
(971.6mm)
5” (127mm)
DIA.
8” (203.2mm) DIA.
GAS INLET
ELECTRICAL
INLET
1 3/4”
(44.5mm)
13 1/4”
(336.6mm)
8 1/2”
(215.9mm)
6 1/2”
(165.1mm)
20 1/8”
(511.2mm)
17 5/8” (447.7mm)
14 3/4”
(374.7mm)
RIGHT
SIDE
LEFT
SIDE
30 1/4”
(768.4mm)
20 1/8” (511.2mm)
36 1/8”
(917.6mm)
41 1/8”
(1044.6mm)
GAS INLET
ELECTRICAL
INLET
RIGHT
SIDE
LEFT
SIDE
32 1/4”
(819.2mm)
1 3/4”
(44.5mm)
13 1/4”
(336.6mm)
8 1/2”
(215.9mm)
6 1/2”
(165.1mm)
20 1/8”
(511.2mm)
30 1/4”
(768.4mm)
5” (127mm)
DIA.
8” (203.2mm) DIA.
17 5/8” (447.7mm)
14 3/4”
(374.7mm)
20 1/8” (511.2mm)
2.1 DIMENSIONS
2.1.1 SEE-THRU (HD4ST, HD4STG AND HD4STC)
2.1.2 PENINSULA (HD4P, HD4PG AND HD4PC)
