6
N415-0560 JUL06.21
: Ensure the gas regulator hose is kink free. Remove the cap or plug from the cylinder
fuel valve. Insert the black QCC1 regulator nipple onto the QCC1 fuel valve. Hand ghten clockwise. Do not
use tools. Leak test all joints prior to using the grill. A leak test must be performed annually and each me
a cylinder is hooked up or if a part of the gas system is replaced.
If this grill is to be connected directly to a house propane gas supply line, follow the instrucons for the
natural gas hook-up. Ensure that the supply pressure is 11 inches water column.
: These connecons must be made by a licensed gas er. This natural gas grill is
supplied with a gas supply hose (complete with a quick disconnect) designed for natural gas and cered for
outdoor use. The gas grill is designed to operate at an inlet pressure of 7 inches water column. Piping and
valves upstream of the quick disconnect are not supplied. The installaon must comply with CAN B149.1
Natural Gas and Propane installaon code in Canada, or to the Naonal Fuel Gas Code, ANSI Z223.1 in the
United States. The gas supply pipe must be suciently sized to supply the BTU/h specied on the rang
plate, based on the length of the piping run.
The quick disconnect must not be installed in an upward direcon and a readily accessible manual shut-o
valve must be installed upstream of, and as close to, the quick disconnect as is feasible. The ared end of
the hose must be connected to the ng on the end of the manifold tube or ex tube (if applicable) as
illustrated in the Natural Gas Hose Aachment diagram. Tighten using two wrenches. (Do not use thread
sealer/pipe dope.) Leak test all joints prior to using the gas grill.
Gas Hook-Up Instrucons
WARNING!
drip pan.
: Set cylinder into hole in boom shelf. Other cylinders may be acceptable
provided they t properly into the tank retaining ring.
