BILEX485 BUILT-IN INSTRUCTIONS
This grill is designed for masonry, NON-COMBUSTIBLE enclosures only, and must be installed and serviced by
a qualied installer to local codes.
1. Aach side mounng brackets to each side of the grill using #1/4-20 x 3/8" screws (N570-0073).
2. Lay the rear trim piece across the back of the opening. To keep it in place, a dab of silicone may be applied
to each wing of the rear trim.
3. Lower the unit in place, the wings on the rear trim should be under the side mounng brackets. Connect
the ex supply line to the ng at the end of the manifold.
4. The enre installaon must be leak tested before operang the unit.
x6
N570-0073 (1/4-20 X 3/8”)
APPLY A DAB OF SILICONE
TO EACH FLANGE TO
SECURE IN PLACE.
